HUAWEI HG8310M GPON 1GE ONU ONT Overview

The Echo Life HG8310M is an indoor optical network terminal (ONT) in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The HG8310M provides one GE Ethernet port. The HG8310M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.

Specification

• Fiber port:   1 GPON interface, single mode / single fiber SC, downlink rate 2.5Gbps, uplink rate 1.25Gbps

• Wavelength:   Tx 1310nm, Rx 1490nm

• Fiber optic interface:   SC / PC

• RX sensitivity:   <-28dBm (1490nm)

• WLAN:   IEEE802.11b / g / n, 300Mbps, built-in antenna

• LAN:   1 * 10/100 / 1000Mbps adaptive Ethernet port, full / half duplex, RJ45 interface

• Throughput:   Throughput up to 900Mbps or higher

• DC power supply:   12V 1A, external AC-DC power adapt

• Button:   Reset, power

• Power:   ≤8W

• Working temperature: -5 - + 55 °C Working humidity: 10-90% (non-condensing)

• Storagetemperature:   -30 ° C - + 60 ° C Storage humidity: 10-90% (non-condensing)

• Dimension:   130 * 105 * 30mm (length * width * height)

• Net weight:   ≤0.2Kg
