Flexi Remote Radio Head 2TX 730 (FRLB) Overview
Part Number: 084811A
Manufacturer: Nokia
Discription: Remote Radio Head FRLB Core 700MHz f/LTE
FRLB specification
|
Property
|
Value
|
|
Output power
|
2x30 W
|
|
MIMO
|
yes, 2TX
|
|
Outdoor installation
|
yes
|
|
SW supported technology
|
FDD-LTE
|
|
TX frequency range
|
729-745 MHz
|
|
RX frequency range
|
699-715 MHz
|
|
DL instantaneous bandwidth
|
16 MHz
|
|
UL instantaneous bandwidth
|
16 MHz
|
|
DL filter bandwidth
|
16 MHz
|
|
UL filter bandwidth
|
16 MHz
|
|
Height
|
400 mm (15.7 in.)
|
|
Depth
|
150 mm (5.9 in.)
|
|
Width
|
400 mm (15.7 in.)
|
|
Weight
|
Without solar shield and
mounting shroud: 27 kg (59.5 Ibs)
|
|
Maximum operational outdoor temperature in
the shade (at constant high ambient
temperature maximum output power might be limited)
|
+55°C (131°F)
|
|
Maximum operational outdoor temperature in
the sun (according to GR-487-Core specification)
|
+50°C (122°F)
|
|
Maximum indoor temperature (this is valid for
fanless products)
|
+45°C (129.2°F)
|
|
Minimum operational temperature (including cold start)
|
-40°C (-40°F)
|
FRLB interfaces
|
Interface
|
Label on the HW
|
Number of interfaces
|
Connector type
|
Additional info
|
|
Power connector
|
DC IN
|
1
|
3-pole screw terminal
|
|
|
Antenna connector
|
ANT
|
2
|
7/16
|
|
|
RF external connector
|
Rx EXT
|
2
|
QMA
|
|
|
Remote Electrical Tilt
|
RET
|
1
|
8-pin circular
|
|
|
External Alarm Connection
|
EAC
|
1
|
D-sub MDR14
|
|
|
Optical interface
|
OPT
|
2
|
SFP
|
|
|
Local Management Port
|
LMP
|
1
|
2x15 pin header
|
|
