Model
|
Size (mm)
|
Watt
|
Input Voltage
|
SMD LED
|
Material
|
PF
|
CRI
|
Cap
|
Beam Angle
|
Light efficiency
|
T5-60CM-10W
|
568*35*22
|
10w
|
AC85-265V
|
SMD2835
|
6063 aviation Aluminum+ PC cover
|
>0.92
|
>80
|
three-pin plug
|
140°
|
100LM/W or more higher
|
T5-120CM-18W
|
1178*35*22
|
18w
|
AC85-265V
|
SMD2835
|
6063 aviation Aluminum+ PC cover
|
>0.92
|
>80
|
three-pin plug
|
140°
|
100LM/W or more higher
|
|
T5-150CM-25W
|
1478*35*22
|
23w
|
AC85-265V
|
SMD2835
|
6063 aviation Aluminum+ PC cover
|
>0.92
|
>80
|
three-pin plug
|
140°
|
100LM/W or more higher
|
一、Installation Step For One LED T5
1、Switch off power supply, wire the three-pin plug. (Note: L:live line ; N: null line ; yellow line: ground line)
2、Put two metal buckles into the place where need to install led tube
3、Put led tube into metal buckles, insert the three-pin plug into led tube, then put the cover into the another end
二、Installation Step For More joint LED T5
1、Switch off power supply, wire the three-pin plug. (Note: L:live line ; N: null line ; yellow line: ground line)
2、Put two metal buckles into the place where need to install led tube
3、Put led tube into metal buckles, put the plug into led tube, then put the cover into the other end
Insert connector into led tube, put led tube into metal buckle, then connect two led tubes with connectors and put the cover into the last led tube’s end, the plug of first led tube connect the socket.
Pay Attention:the total power less than 200w.(60cm led tube t5 connect <20pcs ,120cm<10pcs)
4、Switch on power
Perfect Used for Hotel, bar, counter, showcase, living room, advertisement decoration etc
