EQ23110X-3LCD2

100GbpS QSFP28 PSM4 2km Optical Transceiver

Ø 4 channels full-duplex transceiver modules

Ø Transmission data rate up to 26Gbps per channel

Ø 4 channels 1310nm DFB

Ø 4 channels PIN photo detector array

Ø Internal CDR circuits on both receiver and transmitter channels

Ø Support CDR bypass

Ø Low power consumption <3.5W

Ø Hot Pluggable QSFP form factor

Ø Up to 2km reach for G.652 SMF

Ø Single male MPO(APC 8-degree) connector receptacle

Ø Built-in digital diagnostic functions

Ø Operating case temperature 0°C to +70°C

Ø 3.3V power supply voltage

Ø RoHS 6 compliant(lead free)

Applications

Ø Infiniband DDR/EDR

Ø Datacenter and Enterprise networking
