EXTDxxX-3LCD80(Tunable)
10Gbps Tunable DWDM 80KM XFP Transceiver
Features
- Supports 9.95Gb/s to 11.3Gb/s bit rates
- Monolithically integrated full C-band tunable transmitter
- 50GHz ITU channel spacing with integrated wavelength locker
- C-band-tunable Laser and APD receiver
- Maximum link length of 80km
- Full Duplex LC connector
- Hot-pluggable XFP footprint
- Supports Line-side and XFI loopback
- No Reference Clock required
- Built-in digital diagnostic functions
- Standard bail release mechanism
- Power dissipation <3.5W
- Case temperature range:0°C to 70°C
Applications
Description
- The ETU-Link tunable 10Gb/s XFP transceiver is an integrated fiber
optic transceiver that provides a high-speed serial link at signaling rates
from 9.95Gb/s to 11.35Gb/s. The module complies with the 10Gigabit small form
factor pluggable (XFP) multisource agreement-MSA (INF-8077i) and Tunable XFP
for ITU Frequency Grid Applications（SFF-8477）.
- It complies with the ITU-T G.698.1 standard
with 50GHz channel spacing for SONET/SDH, IEEE DWDM 10GBASE-ZR for 80km reach
(Ethernet), and DWDM 10GFC for 80km reach (Fiber Channel) applications.
- The transceiver integrates the receiver and
transmit path on one module. On the transmit side, the 10Gbps serial data
stream is recovered, retimed, and passed to a modulator driver. The modulator
driver biases and modulates a C-band-tunable integrated laser Mach-Zehnder
(ILMZ), enabling data transmission over single-mode fiber through an
industry-standard LC connector. On the receiver side, the 10Gbps data stream is
recovered from an APD/ trans-impedance amplifier, retimed, and passed to an
output driver. This module features a hot-pluggable XFI-compliant electrical
interface.
