10W Long Range Dual Band Handheld Walkie Talkie Radio
10W Waterproof Handheld Ham Radio Walkie Talkie,With higher ouputpower 10W, numeric keypad, wide-band coverage, 999 channels, cross band VHF to UHF or UHF to VHF. T-650UV has integrated all cutting-edge analog technologies, and is capable of fulfilling any demand on conventional communication.
Quick Details
1.16channels
2.10W/5W/2W Power Switch with Side-key operation
3.Chinese/English Voice Announcement
4.Wide/Narrow Bandwidth Selection 12.5KHz/25KHz
5.CTCSS&DCS non-standard code
6.Battery Saver
7.Low Battery Alert
8.Check battery capacity by handheld operation and will annouce the capacity in current status
9.VOX on/off, VOX level setting, VOX delay time setting
10.DTMF/PTT ID
11.Busy Channel Lockout
12.Scan, Auto scan, Priority Channel Scan, Scan Add, Scan Delete
13.TX Power Level Adjustment by hand operation
14.Monitor / Monitor Momentary
15.Squelch level report, Squelch level adjustment
16.TOT function
17.Emergency Alarm
18.2 Tone
19.Remote Kill,Stun,Activate&Revive
20.Tail Tone Eliminate
21.Auto Power Off
22.Wire Clone
23.PC Software Program
Specification
|
GENERAL
|
|
Frequency
Range
|
136-174MHZ&400-480MHZ
136-174MHZ&450-520MHZ
|
|
Operating
Temperature
|
-20℃to +55℃
|
|
Frequency
Combination
|
please
lock frequency synthesize
|
|
Frequency
Stability
|
±2.5ppm
|
|
Memory
Channel
|
16
|
|
Working
voltage
|
7.4
|
|
Antenna
Impedance
|
50Ω
|
|
Operating
Mode
|
simplex
of co-frequency or alien
|
|
Dimensions
|
135*70*38mm
|
|
Weight
|
255G
|
|
TRANSMIT PART
|
|
RF
power
|
10W
|
|
Modulate
Mode
|
F3E
|
|
Max.Freq.Deviation
|
≤5KHz
|
|
Remain
Wave Radiation
|
≤60db
|
|
Transmitting
Current
|
≤1000mah
|
|
RECEIVER PART
|
|
Sensitivity
|
＜0.20uV (12dB SINAD)
|
|
Squeich
Sensitivity
|
＜0.20uV
|
|
Intermodulation
Antijamming
|
50db
|
|
Audio
Power output
|
500mW
|
|
Receiving
Current
|
≤100mh
|
|
Squelch
Stangby
|
20ma
|
Long Range Handheld 10W Walkie Talkie 15KM
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea: To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days.
