Micro dc mini permanent electromagnet, low voltage, low power supply, widely used for home appliance, electronic products.
Compared with the standard electromagnet, dc permanent electromagnet work type is opposite, power off for holding power on for release.
Products Description
|
Brand
|
Landa
|
Model
|
XH5030
|
|
Place of Origin
|
Guangdong, China
|
Certification
|
CE,ROHS,ISO9001
|
|
Dimension(L*W*H)
|
50*50*30 mm
|
Rated Voltage (V)
|
DC 12/24
|
|
Rated Power(W)
|
9-19
|
Work Model
|
Holding Type
|
|
Holding Force (N)
|
400
|
Stroke(mm)
|
0
|
|
Reset Time(s)
|
0.2
|
Service Life
|
500 Thousand Times
|
|
Material
|
Iron
|
Lead Wire Length(mm)
|
300
|
|
Install Style
|
screw
|
Tolerance of Dimension
|
gb/t1804-m
|
|
Water-proof
|
IP65
|
Insulation Class
|
B
|
|
Residual Magnefism
|
/
|
Duty Cycle
|
50%-100%
|
|
Working Temperature
|
-10°C-100°C
|
Thread Size(mm)
|
M4
|
|
Thread Depth(mm)
|
4
|
Payment Term
|
TT,PAYPAL
|
|
Sample Order
|
Yes
|
Warranty
|
1 year
|
|
MOQ
|
2 pcs
|
Supply Ability
|
5000 pcs per Week
|
|
Delivery Time
|
3 Days
|
Port of Loading
|
Zhongshan
|
|
Weight
|
Packaging Details
|
Shipment Details
|
|
N.W.(KG)
|
G.W.(KG)
|
Product Size(mm)
|
Carton Box Size(mm)
|
20GP
|
40GP
|
40HQ
|
|
0.35
|
0.35
|
50*50*30
|
350*310*180
|
/
|
/
|
/
|
Product Features
Small size, high suction,with force power off and without force power on Smooth and flat surface, saving energy, safe and reliable
Easy to install Four 7mm depth M4 mounting teeth in the bottom , easy to install and operate.
Materials
High quality iron house & core High temperature resistance lead wire and copper wire, efficient conductivity, outlet can be customized Epoxy filled, IP65 waterproof class
OEM/ODM is welcome
11 years of designing and producing experience CE, ROHS, ISO9001 certification. Good quality, best service, competitive price.Welcome to our factory
