SPECIFICATION
Manufacturer Part Number: 140DAO84210
Product Type: Discrete output module Modicon Quantum - 16 O - 83..253 V AC
Country of Origin: FRANCE
Brand/Manufacturer: SCHNEIDER
DESCRIPTION
|
group of channels
|
4 groups of 4 channels
|
|
supply frequency
|
47...63 Hz
|
|
voltage drop
|
1.5 V
|
|
discrete output voltage
|
83...253 V AC
|
|
addressing requirement
|
1 output word
|
|
absolute maximum output
|
300 Vrms for 10 s AC
|
|
|
400 Vrms 1 cycle AC
|
|
maximum load current
|
16 A rms per module
|
|
|
2 mA rms 115 Vrms off state leakage per output
|
|
|
2.5 mA rms 230 Vrms off state leakage per output
|
|
|
3 A rms 170...253 V per output
|
|
|
4 A rms 85...132 V per output
|
|
|
4 A rms per group
|
|
surge current
|
<= 10 A during 3 cycles per point
|
|
|
<= 20 A during 2 cycles per point
|
|
|
<= 25 A during 3 cycles per group
|
|
|
<= 30 A during 1 cycle per point
|
|
|
<= 30 A during 2 cycles per group
|
|
|
<= 45 A during 1 cycle per group
|
|
dV/dt
|
400 V/ms
|
|
response time
|
<= 0.5 ms at state 0 to state 1
|
|
|
<= 0.5 ms at state 1 to state 0
|
|
fault indication
|
Blown fuse
|
|
|
Loss of field power
|
|
protection type
|
Internal by RC filter
|
|
|
Internal output protection by 5 A fuse
|
|
power dissipation
|
1.85 + (1.1 V x total module load current)
|
