SCHNEIDER 140DDO84300
World's Largest Selection of Controller System Components Available for Immediate Shipment!
Sunny Guo
Email:sales2@amikon.cn (Click!)
Skype:aritang111
TEL:+86-0592-5321698
Phone:+86-18020776791
Give me a Inquiry, I will get you back asap.
SPECIFICATION
Manufacturer Part Number: 140DDO84300
Product Type: Discrete output module Modicon Quantum - 16 O - 10..60 V DC
Country of Origin: FRANCE
Brand/Manufacturer: SCHNEIDER
DESCRIPTION
|
group of channels
|
2 groups of 8
|
|
discrete output logic
|
Negative logic (sink)
|
|
addressing requirement
|
1 output word
|
|
discrete output voltage
|
10...60 V DC
|
|
output voltage limits
|
10.2...72 V
|
|
absolute maximum output
|
72 V permanent
|
|
voltage drop
|
<= 1 V 2 A
|
|
maximum load current
|
12 A per module
|
|
|
6 A per group
|
|
surge current
|
<= 7.5 A for 50 s
|
|
response time
|
<= 1 ms at state 0 to state 1
|
|
|
<= 1 ms at state 1 to state 0
|
|
leakage current
|
<= 1 mA 60 V
|
|
load inductance
|
Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz)))
|
|
associated fuse rating
|
2 A each point
|
|
|
8 A per group
|
|
isolation between channels and bus
|
2500 Vrms DC for 1 minute
|
|
isolation between group
|
700 Vrms DC for 1 minute
|
|
protection type
|
Internal output protection by 8 A fuse per group
|
|
power dissipation
|
1 W + (1 V x total module load current)
|
