15M Width Double Decker Exhibition Tents
Our 15m double decker tent is made of multi-level temporary structure systems. Which can provide more space for exhibition events.
This structure are available in both two and three storey, in the second or third floor it can be designed into different tents, such as “ A frame, Curve and Cube shape etc.
Width of tent can be from 10-25m, length is unlimited. To add further to their flexibility, 5mx5m modules can be eliminated on the ground floor to create open galleried areas.
Many accessories can be assemble to this tent, which will be good for the exhibition events. We are sure it is attractive and you will like it.
Available sizes:
● Clear span available from 10m to 40m.
● Length: adjustable by 5m unit.
Frame:
● No maintenance required; main aluminum frame profile is 300x125x5mm.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
● Modular character for diverse combination and expansion.
Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
The Specification of 15M Width Double Decker Exhibition Tents:
|
Type
|
Span
(m)
|
Side
height (m)
|
Ridge
height (m)
|
Bay
Distance (m)
|
Roof
Pitch
|
Longest
Component (m)
|
Wind
Load (km/h)
|
|
XLS10/6.8-5DD
|
10
|
6.8
|
8.5
|
5
|
18°
|
6.5
|
100
|
|
XLS15/6.8-5DD
|
15
|
6.8
|
9.3
|
5
|
18°
|
6.5
|
100
|
|
XLS20/6.8-5DD
|
20
|
6.8
|
10.2
|
5
|
18°
|
6.5
|
100
|
|
XLS25/6.8-5DD
|
25
|
6.8
|
11
|
5
|
18°
|
8.2
|
100
|
|
XLS30/6.8-5DD
|
30
|
6.8
|
11.8
|
5
|
18°
|
10.7
|
100
|
|
XLS40/6.8-5DD
|
40
|
6.8
|
13.5
|
5
|
18°
|
10.7
|
100
|
