Product Name:15x30m Wedding Marquee With French Window
The 15x30m Wedding Marquee widely approved method of modular construction allows the user to create solutions for providing cost-efficient, functional, safe and attractive venues in wedding and ceremony. Used as reception and catering,Superb Wedding Marquue also provide beautiful linen, lighting, air-con,flooring and any accessories that your wedding need.
15x30m wedding Tent marquee system is supplied with a standard eave height of 2.60m and like all Superbtent structures, Wedding Tent marquees are fully modular in design therefore allowing them to be extended to create unlimited lengths in increments of 3.00m & 5.00m modular sections.
To add further to their flexibility, the robust Warty Tent marquee system is available in a number of aesthetically pleasing design options – customers can choose from the following designs; Classic “A” Frame, Curved Roof, High Peak Roof, Hip End, Multi-Sided and 2 & 3 Way Split Conversion designs on 3.00m modular bays.
The specification of 15x30m Wedding Marquee:
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
BS10/4-5
|
10
|
4
|
5.5
|
5
|
18°
|
6
|
100
|
|
BS15/4-5
|
15
|
4
|
6.4
|
5
|
18°
|
8.5
|
100
|
|
BS20/4-5
|
20
|
4
|
7.1
|
5
|
18°
|
10.7
|
100
|
|
BS25/4-5
|
25
|
4
|
7.9
|
5
|
18°
|
10.7
|
100
|
|
Main frame Profile
|
204x120x4mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Twin Steel Plate
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
The accessories of 15x30m wedding marquee:
