The Allen-Bradley 1746-IA16 is a logic controller module that is configurable and programmable. It has a 0 - 60 C operating temperature and it has standard features. It weighs 0.34 kg and has 5" x 2" x 6" (13 cm x 5 cm x 15 cm) dimension. The controller module has 0.27 watts per point with min to 0.425 Watts and a total of 4.8 Watts. The module has a 100 - 120V AC input signal voltage category with 16 points per common and 16 inputs.
The 1746-IA16 is a general-purpose input application. The mounting is a chassis-type and has 16 channels. The operating voltage ranges from 85 - 132V AC input signal. It has a 16-channel digital AC input module for a programmable controller. The operating voltage is 85 - 132V AC at 47 - 63 Hz operating frequency. The back-plane current consumption at 5V DC is 0.085 mA and it is 0.0 A at 24V DC.
The signal for the ON-delay is at its max at 35 ms and the signal for the OFF-delay is at max at 45 ms. While the maximum OFF-state voltage reaches 30V AC and OFF state current of 2 mA. The input current at 120V AC is 12 mA nominal. The 1746-IA16 has an inrush current time duration at maximum to 500 microseconds and 0.8 mA maximum inrush current.
|
Attribute
|
|
1746-IA16
|
|
|
|
|
|
Voltage category
|
|
100/120V AC signal input
|
|
|
|
|
|
Number of inputs
|
|
16
|
|
|
|
|
|
Points per common
|
|
16
|
|
|
|
|
|
Voltage, operating
|
|
85...132V AC @ 47...63 Hz
|
|
|
|
|
|
Signal delay, max
|
|
On = 35 ms
|
|
|
|
Off = 45 ms
|
|
|
|
|
|
Off-state voltage, max
|
|
30V AC
|
|
|
|
|
|
Off-state current, max
|
|
2 mA
|
|
|
|
|
|
Input current
|
|
12 mA @ 120V AC, nom
|
|
|
|
|
|
nrush current, max
|
|
0.8 A
|
|
|
|
|
|
Inrush current time duration, max
|
|
0.5 ms
|
Allen Bradley 1746-IA16
1746-IA16 | Allen Bradley | SLC 500 Digital I/O Modules
Email:sales3@amikon.cn
Part Number:
|
1746-IA16
|
|
Module Type:
|
Digital AC Input Module
|
|
Series:
|
SLC 500
|
|
Voltage Range:
|
85-132 Volts AC
|
|
Backplane Current (5 Volts DC):
|
85 milliamps
|
