The 1746-IO12 SLC 500 Input/Output Combine Module by Allen-Bradley is a 120V AC combined I/O module with Six 120V AC inputs and six 100-120V AC relay contact outputs. It has an operational input voltage range between 85 and 132V AC and an output range of 5-265V AC at 47-63 Hz and 5-125V DC also at 47-63Hz.
The 1746-IO12 has a Chassis backplane current draw of 0.090A at 5V DC and one of 0.070A at 24V DC. Its output point has a contact rating of 2.0A output in continuous current and a maximum output power of 28VA. The signal on both the input and output points has a maximum delay time of 35ms for ON state and 45ms for OFF state.
The 1746-IO12’s contact output is a Normally-Open contact (N.O.) type and each output has a nominal continuous current of 1.5A at 120V AC and one of 1.2A at 24V DC. It has 0.27W per input point, 0.133W per output point maximum power dissipation, and the aggregate heat dissipation in the module is 4.60W.
The 1746-IO12 has a 0-60 °C (32-140 °F) functional temperature range at a humidity between 5-95% without condensation and it can be stored at a temperature range between -4 and 85 °C (-40 and 185 °F). It provides Electro-optical isolation tested at 1500V between the I/O terminals and the control logic and it offers a NEMA standard ICS 2-230 rated noise immunity. The1746-IO12 can withstand a functional vibration of 2.5G at 57-200Hz operational vibration and it can maintain its optimum function at a 30G operational shock.
|
Attribute
|
|
1746-IO12
|
|
|
|
|
|
Points per module
|
|
6 inputs
|
|
|
|
6 outputs
|
|
|
|
|
|
Points per common
|
|
6
|
|
|
|
|
|
Voltage category
|
|
120V AC
|
|
|
|
|
|
Voltage, operating (inputs)
|
|
85...132V AC
|
|
|
|
|
|
Voltage category (outputs)
|
|
100/120V AC Relay contact output
|
|
|
|
|
|
Voltage, operating (outputs)
|
|
5...265V AC
|
|
|
|
5...125V DC
|
Allen Bradley 1746-IO12
1746-IO12 | Allen Bradley | SLC 500 Digital I/O Modules
Email:sales3@amikon.cn
Part Number:
|
1746-IO12
|
|
Module Type:
|
Digital I/O Combination Module
|
|
Series:
|
SLC 500
|
|
Operating Voltage:
|
85-132 Volts AC
|
|
Inputs:
|
6
|
