The Allen-Bradley 1747-L524 is an SLC 500 processor. Also referred to as an SLC 5/02 controller, this processor has a maximum memory of 4000 modules for instructions and a maximum of 4096 modules each for discrete input and output. You can use more than 60 types of modules, such as analog, digital, and scanner modules, for this processor. However, this processor is not compatible with the 1746-BLM and 1746-MPM modules.
Installing scanner modules to this processor will allow you to add DeviceNet, ControlNet, and Universal Remote I/O to the system, as well as add 19 additional instructions. This processor also has a maximum of 480 local analog I/O and a maximum local chassis/slot of 3/30.
Note that no additional data storage can be installed with this processor.
However, you can use optional EEPROM modules. These memory modules allow you to save the contents of the processor RAM and load the data saved in the EEPROM memory to the processor RAM. The DH-485 communication port available with this processor is set to receive and initiate instructions but it requires the 1747-PIC if you will connect the port for programming.
Status indicators are available for this processor. The 1747-L524 processor can have 71 programming instructions and it can be configured using the RSLogix 500, PLC-500 A.I. Series, HHT, and APS programming software. It also has a user-replaceable battery that is estimated to last for an average of 2 years. This processor, measuring 145 x 35 x 142 mm, can be mounted using a chassis and it has an open-style enclosure.
|
Specification
|
|
1747-L524
|
|
|
|
|
|
Program memory
|
|
4K instructions
|
|
|
|
|
|
Additional data storage
|
|
0
|
|
|
|
|
|
Maximum I/O capacity
|
|
4096 discrete inputs
|
|
|
|
4096 discrete outputs
|
|
|
|
|
|
Programming software
|
|
RSLogix 500
|
|
|
|
|
|
Programming instructions
|
|
71
|
|
|
|
|
|
Typical scan time
|
|
4.8 ms/K
|
|
|
|
|
|
Bit execution (XIC)
|
|
2.4 µs
|
|
|
|
|
|
DH-485 communication
|
|
receive or initiate
|
|
|
|
|
|
Power supply loading @ 5V dc
|
|
90 mA
|
|
|
|
|
|
Program scan hold-up time
|
|
20 ms to 3 s (dependent on power supply loading)
|
Allen Bradley 1747-L524
1747-L524 - In Stock | Allen Bradley PLC SLC 500
Email:sales3@amikon.cn
Part Number:
|
1747-L524
|
|
Module Type:
|
SLC 5/02 Processor
|
|
Series:
|
SLC 500
|
|
Inputs:
|
4096
|
|
Outputs:
|
4096
|
