The Allen-Bradley 1756-EN2F is a part of the ControlLogix Communication Module series. It is an EtherNet/IP (Ethernet Industrial Protocol) interface Communication Module. It supports general messaging, real-time I/O messaging, and information exchange for applications like Real-Time Control, Time Synchronization, and Motion.
The 1756-EN2F bridge also has a CIP safety standard for allowing simultaneous transfer of safety and control data and diagnostics information. It uses advanced communication chips and physical media.
The 1756-EN2F Module has 100 Mbps EtherNet/IP communication rates and uses fiber. It supports 256 Logix and 128 TCP/IP communication connections. It can support a maximum of 8 axes for integrated motion on the Ethernet/IP Network. It draws 1.2 A current at 5.1V DC and 3 mA at 24V DC. It has a maximum power dissipation of 6.2 W and thermal dissipation of 21.28 BTU/hr. It can be installed in any ControlLogix Chassis slot.
For wiring, it uses unshielded RJ45, category 5, twisted-pair cable connectors to interface with the controller. The 1756-EN2F bridge is configured using RSLinx software to be used at the workstation. To operate EtherNet/IP network parameters such as IP address, Subnet masks, Gateway etc. must be defined.
|
Attribute
|
|
1756-EN2F
|
|
|
|
|
|
Enclosure type rating
|
|
None (open-style)
|
|
|
|
|
|
USB connector
|
|
Ethernet BNC
|
|
|
|
USB Type B receptacle
|
|
|
|
|
|
USB port
|
|
USB 1.1
|
|
|
|
USB Device
|
|
|
|
|
|
Recommended USB cable
|
|
Samtec cable, PN RSP-199350
|
|
for USB port
|
|
|
|
|
|
|
|
Fiber connector
|
|
LC2
|
|
|
|
|
|
Fiber cable
|
|
100BASE-FX-compliant multimode GI fiber cable
|
|
|
|
|
|
Module location
|
|
Any slot in the ControlLogix chassis
|
|
|
|
|
|
Backplane current
|
|
1.2 A @ 5.1V DC
|
|
|
|
3 mA @ 24V DC
|
|
|
|
|
|
Isolation voltage,
|
|
No isolation between USB and system
|
|
continuous
|
|
|
Allen Bradley 1756-EN2F
1756-EN2F | Allen Bradley | ControlLogix EtherNet/IP Module
Email:sales3@amikon.cn
Part Number:
|
1756-EN2F
|
|
Series:
|
ControlLogix
|
|
Module Type:
|
Ethernet Communication Module
|
|
Maximum Multicast Tags:
|
32
|
|
Ethernet-IP Communication Rate:
|
10-1000 Megabites per second
|
