The Allen-Bradley 1756-L61 is a ControlLogix controller. It can either be a Series A or a Series B controller. It has 2 MB user memory and 478 kb I/O memory available, with an optional non-volatile storage memory of 128 MB but you can only use the 1784-CF128 CompactFlash memory card. It is a chassis-based controller and can be placed in any available slot of the 1756 ControlLogix chassis. Note that the only compatible chassis for this controller are 1756-A4, 1756-A7, 1756-A10, 1756-A13, and the 1756-A17. It has an open-style type of enclosure and can support up to a maximum of 250 controller connections.
It also has a built-in RS-232 serial communication port. The serial port communication available with this controller are DF1 full/half-duplex, ASCII, DF1 radio modem, Modbus via logic, and DH-485.
It has a maximum digital I/O of 128,000, a maximum analog I/O of 4,000, and a maximum total I/O of 128,000. Controller tasks of the 1756-L61 include 32 tasks, 100 programs per task, and event tasks: all event triggers. The 1756-L61 has various communication options, such as ControlNet, Data Highway Plus, EtherNet/IP, DeviceNet, SynchLink, Remote I/O, and third-party process and device networks.
|
Attribute
|
|
1756-L61
|
|
|
|
|
|
User memory
|
|
2 MB
|
|
|
|
|
|
I/O memory
|
|
478 KB
|
|
|
|
|
|
Optional nonvolatile memory storage
|
|
128 MB (1784-CF128)
|
|
|
|
|
|
Digital I/O, max
|
|
128,000
|
|
|
|
|
|
Analog I/O, max
|
|
4000
|
|
|
|
|
|
Total I/O, max
|
|
128,000
|
|
|
|
|
|
Replacement battery
|
|
Series A: 1756-BA1, 1756-BATM, 1756-BATA
|
|
|
|
Series B: 1756-BA2
|
|
|
|
|
|
Current draw @ 5.1V DC
|
|
1200 mA
|
|
|
|
|
|
Current draw @ 24V DC
|
|
14 mA
|
|
|
|
|
|
Power dissipation
|
|
3.5 W
|
Allen Bradley 1756-L61
1756-L61 | Allen Bradley | ControlLogix and GuardLogix Controllers
Email:sales3@amikon.cn
Part Number:
|
1756-L61
|
|
Series:
|
ControlLogix
|
|
Module Type:
|
Processor Module
|
|
Nonvolatile Memory:
|
See Compact Flash Card 1784-CF64
|
|
Maximum Analog I-O:
|
4,000 Input, 2,000 Output
|
