The Allen-Bradley 1756-OB16E is a ControlLogix DC digital output module. It has been fused electronically by group and has 16 outputs, with 8 points per group. A Removable Terminal Block housing, or RTB, is necessary before installing it to a compatible ControlLogix chassis. For this module, you can use the 1756-TBNH RTB or the 1756-TBSH RTB, which both have 20 pins.

Using the RSLogix 5000 programming software, it is possible to configure the 1756-OB16E module's transition from Program state to Fault state, the output state in Fault mode, or the output state in program mode. Other features of this module are multiple output point densities, configurable point-level output states, isolated and non-isolated varieties of output modules, and output data echo.

Allen Bradley    1756-OB16E

1756-OB16E | Allen Bradley | I/O Module

         sales3@amikon.cn

The 1756-OB16E module has a voltage category of 12/24V DC source, as well as an operating voltage of 10 to 31.2V DC. Its total backplane power is 1.32 W and a current draw of 250 milliamps at 5.1V and 2 milliamps at 24V.
