The ControlLogix 1756-RIO module connects a ControlLogix processor to a
remote I/O network.
As a scanner, with one remote I/O channel, the 1756-RIO module scans I/O on
a remote I/O network.
The module supports the following:
• All remote I/O baud rates: 57.6, 115.2, 230.4 Kbaud
• Rack numbers from 0…76 octal
• All combinations of partial racks
• Up to 32 physical adapters
To support 32 physical adapters, you must use an 82 resistor; 150
resistors allow only 16 adapters.
• Block transfers at all possible locations
The module can update block transfers (BTs) automatically via the 1756-RIO
module or can be controlled by the ControlLogix controller. It transfers all I/O
via produced/consumed connections over the backplane to the controller
|
Attribute
|
|
1756-RIO
|
|
|
|
|
|
Module location
|
|
1756 ControlLogix chassis
|
|
|
|
|
|
Backplane current, max
|
|
450 mA @ 5.1V DC
|
|
|
|
5 mA @ 24 V DC
|
|
|
|
|
|
Isolation voltage
|
|
50V (continuous), basic insulation type, RIO
|
|
|
|
communication lines to backplane
|
|
|
|
Type tested at 500V AC for 60 s
|
|
|
|
|
|
Power dissipation
|
|
2.5 W
|
|
|
|
|
|
Screw terminal torque
|
|
0.5…0.6 N•m (5…7 lb•in)
|
|
|
|
|
|
Wiring category
|
|
2 - on communication ports
|
|
|
|
|
|
Wire size
|
|
0.52 mm2 (20 AWG)
|
Allen Bradley 1756-RIO
1756-RIO - In Stock | Allen Bradley PLC ControlLogix
Email:sales3@amikon.cn
Attribute
|
1756-RIO
|
|
EFT/B immunity
IEC 61000-4-4
|
±2 kV at 5 kHz on communication
ports
|
|
Surge transient immunity
IEC 61000-4-5
|
± 2 kV line-earth (CM) on
communication ports
|
|
Conducted RF immunity
IEC 61000-4-6
|
10V rms with 1 kHz sine-wave 80%
AM from 150 kHz…80 MHz
|
