The Allen-Bradley 1769-IF4 is a Compact I/O analog module. It can convert and store the analog data digitally. Four differential or single-ended channels are available for this module and it can perform auto-calibration when it is enabled initially in a channel or when the channel has a different configuration than that of the previous channel.
Note that this module does not provide loop power for analog inputs and that it is necessary to have a power supply that matches the input transmitter’s specifications. The user can wire the 1769-IF4 module's channels as single-ended or differential inputs. The 1769-IF4 also has a common mode rejection ratio that is greater than 60 dB and a normal mode rejection ratio of -50 dB at 50 to 60 Hertz.
It has an open-type enclosure and it can be mounted on a DIN rail or panel mount. The connection cables compatible with the 1769-IF4 are 22-14 AWG solid and 22-16 AWG stranded. This module also comes with an LED status indicator and measures 87 x 35 x 118 millimeters.
|
Attribute
|
|
1769-IF4
|
|
|
|
|
|
Inputs
|
|
4 differential or single-ended
|
|
|
|
|
|
Input range
|
|
±10V
|
|
|
|
0…10V
|
|
|
|
0…5V
|
|
|
|
1…5V
|
|
|
|
0…20 mA
|
|
|
|
4…20 mA
|
|
|
|
|
|
Current draw @ 5.1V
|
|
120 mA
|
|
|
|
|
|
Current draw @ 24V
|
|
60 mA
|
|
|
|
|
|
Heat dissipation, max
|
|
2.52 W
|
|
|
|
|
|
Rated working voltage
|
|
30V AC/30V DC
|
|
|
|
|
|
Power supply
|
|
1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
|
Allen Bradley 1769-IF4
1769-IF4 | Allen Bradley | Compact I/O Analog Modules
Email:sales3@amikon.cn
|
Part Number:
|
1769-IF4
|
|
Product Line:
|
CompactLogix
|
|
Module Type:
|
4 Channel Analog Input Module
|
|
Input Type:
|
Analog Output
|
|
Communication Cable :
|
4 Point
|
