The Allen-Bradley 1769-L35CR is a Logix controller that runs on RSLogix5000 software and supports industrial CompactFlash cards that provide RAM memory. Devices can connect to the 1769-L35CR using 1756-CP3 and 1747-CP3 cables through an RS-232 port. The 1769-L35CR must be strategically placed within the 4 power supply modules. It can support up to 30 I/O modules connectable with 2 unique expansion cables to up to 3 I/O banks. The I/O banks of the 1769-L35CR come with a separate power supply and the controller’s uniqueness demands that only 1 1769-L35CR be connected to a Logix system at a time.
The 1769-L35CR has a 30-module expansion capacity. The 1769-L35CR has a (5V) DC draw current of 680mA and a heat dissipation of up to 4.36W. The 1769-L35CR offers a maximum wire insulation of 30V, and it has a backplane current of 680mA (5V DC). It can be mounted easily with a DIN rail mount at 20G operational shock rating or on a panel mount at the same shock rate.
The 1769-L35CR has a 5G operational vibration at a frequency of 10-500 HZ. It can withstand a mounting torque of 1.1 – 1.8 Nm. The 1769-L35CR compact Logix controllerhas a storage temperature between -40 and 85 °C (-40 and 185 °F), and functions efficiently at a temperature range between 0 and 60 °C (32 and 140 °F). It has and 0 – 95% non-condensing relative humidity and weighs approximately 0.32 kg (0.70 lb).
|
Attribute
|
|
1769-L35CR
|
|
|
|
|
|
User memory
|
|
1.5 MB
|
|
|
|
|
|
Optional flash memory
|
|
1784-CF64
|
|
|
|
1784-CF128
|
|
|
|
|
|
Number of I/O modules, max
|
|
30
|
|
|
|
|
|
Number of I/O banks, max
|
|
3
|
|
|
|
|
|
Number of expansion I/O modules,
|
|
30 1769 modules
|
|
max
|
|
|
|
|
|
|
|
Current draw @ 5V DC
|
|
680 mA
|
|
|
|
|
|
Current draw @ 24V DC
|
|
40 mA
|
|
|
|
|
|
Power dissipation
|
|
4.36 W
|
Allen Bradley 1769-L35CR
1769-L35CR - In Stock | Allen Bradley PLC CompactLogix
Email:sales3@amikon.cn
Part Number:
|
1769-L35CR
|
|
Product Line:
|
CompactLogix
|
|
Module Type:
|
Processor Module
|
|
Software:
|
RSLogix5000
|
|
Shipping Weight:
|
2 lbs
|
