The programmable controller 1785-L80B is a central part of each control system based on the Allen Bradley PLC-5 series. The 1785-L80B connects local, extended, and remote I/O modules on various communication interfaces into one control system. Four built-in ports are available on the 1785-L80B controller. The ports are marked as channel 1A, channel 1B, channel 2A, and channel 2B.
All ports can be configured and used as remote I/O scanners, remote I/O adapters, and DH+ communication interfaces. DH+ communication can be used both for remote programming and monitoring of the 1785-L80B and for creating a peer-to-peer communication network between the various PLC-5 controllers. Remote I/O connection is used for real-time data exchange between the controller and I/O, operator interface, and other functions. All four channels on the 1785-L80B can function as remote I/O scanners or remote I/O communication adapters.
Remote I/O scanner mode reads and writes I/O information between a controller and a remote I/O device. In this mode, the 1785-L80B is a supervisory controller for other controllers that are in adapter mode and for remote I/O adapter modules. When any of the four channels 1A, 1B, 2A, or 2B, function in remote I/O adapter mode, the controller monitors its controller-resident local I/O while communicating with the supervisory controller via a remote link.
|
Part Number:
|
|
1785-L80B
|
|
|
|
|
|
Max Analog I/O:
|
|
3072
|
|
|
|
|
|
I/O Scan Time Per Rack:
|
|
10 ms at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at
|
|
|
|
230.4 mbits/s
|
|
|
|
|
|
Max I/O Chassis Total:
|
|
93
|
|
|
|
|
|
Max I/O Chassis Extended
|
|
0
|
|
Local:
|
|
|
|
|
|
|
|
Max I/O Chassis Universal
|
|
32 Max. Per I/O Link
|
|
Remote:
|
|
|
|
|
|
|
|
RS-232-C/422-A/423- A
|
|
1
|
|
Ports:
|
|
|
|
|
|
|
|
Control Coprocessor
|
|
Yes
|
|
Expansion Port:
|
|
|
Allen Bradley 1785-L80B
1785-L80B | Allen Bradley | PLC-5 Backup Communication Module
Email:sales3@amikon.cn
Part Number:
|
1785-L80B
|
|
Processor:
|
PLC-5/80
|
|
Module Type:
|
Standard Processor
|
|
Max User Memory Words:
|
100 Kilowords
|
|
Max Total I/O:
|
3072 (any mix) or 3072 in +
3072 out (complementary)
|
