Technical Specifications for 1791D-0B8P
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
I/O Count
|
32 points
|
|
Part Number/Catalog No.
|
1791D-0B8P
|
Inrush Current
|
30A for 8 ms
|
|
Module Type
|
Output Module
|
Input Voltage range
|
10-30V dc
|
|
Manufacture Year
|
2022
|
DeviceNet Power
|
11-25V dc
|
|
Product Package
|
Original Package
|
UPC
|
1018468554500
|
About 1791D-0B8P
|
The 1791D-0B8P contain several features: power supply, DeviceNet I/O adapter, and I/O circuit. The device power of this module is 10 to 30 Volts DC. Thus, it can accommodate a broad range of power supplies and many voltage levels. There is also output short-circuit protection. This feature would prevent any damage due to wiring mistakes. The I/O block is located near the sensors and actuators. This can help you to reduce wiring cost and time needed to install the module.
The 1791D-0B8P is a DC compact block base module I/O. The 1791D-0B8P is one of 1791D series. This module has 8 outputs and no inputs. However, you can expand the number of inputs and outputs by using an expansion module. The 1791D-0B8P also has several product certifications such as CE marked for all applicable directives, UL, UL hazardous class I, C-UL, and C-UL hazardous class I. The enclosure of this module follows IEC IP20 standard.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
