Technical Specifications

• Light Sources: 19x15W 4in1 OSRAM RGBW LED
• Beam Angle: 8°~ 60°
• Power Consumption: 300W
• Power Voltage: AC 95 -240V, 50/60Hz
• Dimension: 33*23*37 cm
• Packing Dimension: 410x330x490mm
• Net Weight: 10Kgs
• Gross Weight: 12Kgs

Control

• DMX Channel: 20/28 Channel
• Control Modes: DMX,
• Software Upgrade: Firmware update via DMX link

Pan/Tilt

• Pan/Tilt: 540°/ 270°
• Pan/Tilt Resolution: 16 bit

Construction

• Display: LCD Display
• Data In/Out socket: 3-pin & 5-pin XLR sockets
• Power Socket: Powercon in/out
• Protection Rating: IP20

Features

• Motorized liner zoom system, zoom range: 7°~60°
• Outstanding color macro effect
• Dimmer: 0~100% smooth dimming
• Variable strobe effects
• Fast, quiet operation and flicker free
