Overview
1AB196370008 WMUIAF3 ALCATEL-LUCENT 1696 METROSPAN OPTICAL SFP MODULE WMUIAF3CAA.
SFP OC48-LR, SFP, 2.5Gb/s, 40km, 1310nm, Duplex LC, DDM
Product Description
-
Single Fiber Bi-directional Data Link
-
Hot-Pluggable SFP Footprint
-
Dual LC Connectors
-
Wide Distance Supported from 500m to 120km
-
Digital Diagnostic Functions Optional
-
Metal Enclosure for Lower EMI
-
Comply with SFP MSA
-
Comply with IEEEstd 802.3
-
Single +3.3V Power Supply
-
RoHS-6 Compliant
Specification
|
Media Type:
|
Single-Mode Fiber
(SMF)
|
|
TX Wavelength:
|
1310 nm.
|
|
RX Wavelenght:
|
1310 nm.
|
|
Minimum Optical Budget:
|
18
dB
|
|
Maximum Distance:
|
40km
|
|
Supported Data Rate:
|
100-2.67Gbps
|
|
Supported Applications:
|
Gigabit
Ethernet (1.25 Gbps), 100M
Ethernet (100Mbps), 2G
Fiber Channel (2.125 Gbps), 1G
Fiber Channel (1.0625 Gbps), STM-1
(155Mbps), STM-4
(622Mbps), STM-16
(2.488 Gbps), ODU0
(1.244Gbps), ODU1
(2.498Gbps), OTU1
(2.66Gbps), CPRI
option 1 (614.4 Mbps), CPRI
option 2 (1228.8 Mbps), CPRI
option 3 (2.458 Gbps), OBSAI
RP3 x 1 (768 Mbps), OBSAI
RP3 x 2 (1.536 Gbps)
|
|
DDM/DOM:
|
Support
|
|
Temperature Range:
|
Standard 0°-70°C
|
|
Connectors:
|
Double
LC
|
|
Tx Wavelength Bandwidth:
|
100 nm
(1260-1360 nm)
|
|
Rx Wavelength Bandwidth:
|
100 nm
(1260-1360 nm)
|
|
Minimum Transmitting Power:
|
-2
dB
|
|
Maximum Transmitting Power:
|
3
dB
|
|
Receiver Sensitivity:
|
-20 dBm
|
|
Receiver Overload:
|
-3
dBm
|
|
Dispersion:
|
300
ps/nm
|
|
Transmitter Type:
|
DFB Laser
|
|
Receiver Type:
|
APD Photodiode
|
|
Power:
|
+3.3V single
power supply
|
|
Chipset:
|
MAXIM, MINDSPEED, SEMTECH
|
|
Compliance:
|
CE, Class 1 FDA
and IEC60825-1 Laser Safety Compliant, INF-8074i, RoHS, SFP MSA
|
|
Transceiver Type:
|
SFP
|
|
Port Interface
|
1 x 2.5GBase LC
|
|
Interface Details
|
2.5GBase OC-48/STM-16/2.5G SONET LR1
|
|
Data Rate
|
2.5 Gbps
|
|
Distance
|
40km (24.9 miles)
|
|
Digital Diagnostics (DDM)
|
Yes
|
|
Connection
|
Single-mode Fiber (SMF)
|
|
Hot Swappable
|
Yes
|
|
Dimensions
|
0.50" x 0.50" x 2.25"
|
