1KW 2KW 3KW wind turbine generator charge controller
Description of wind charge controller
Feature of wind charge controller
l Control
using common positive polarity way, double lines for solar array
l Digital
design, module structure, high stability and reliability
l Wind-turbine
brake setting with user-key be programmable
l LCD
equipped (backlighting) to show parameters of system running status
l High
efficiency with by PWM charging method
l Multi-protections
such as anti-reverse connection, no charging reversely while night. And
Over-charge, limited charging current &voltage protections for battery
l User
can adjust setting of battery management system(BMS) and charging controlling
l With
alarm function in system abnormal status
l Equipped
with data communication function (optional)
l Intelligent
cooling system inset
Topology of wind charge controller
Technical Data of wind charge controller
|
System
Capability
|
|
Model
|
1KW/24V,48V
|
2KW/48V,96V
|
3KW/48V,96V
|
5KW/96V,120V,240V
|
|
Wind-turbine power[KW]
|
1
|
2
|
3
|
5
|
|
Rated
wind-turbine voltage[V]
|
28.8 57.6 115.2 144 288
|
|
PV Module
power[W]
|
300
|
600
|
1000
|
1500
|
|
Rated battery
voltage[V]
|
24 48 96 120 240
|
|
Electrical parameters
|
|
Consumption at
standby [mA]
|
≤60
|
|
Consumption at
night [mA]
|
≤20
|
|
OperatingTemperatureRange
|
-25℃ ～ +60℃
|
|
Cooling Method
|
Convection with double cooling fans
|
|
Operating
temperature
|
0%～98% Non-condensing
|
|
Altitude [m]
|
≤2000
|
|
Terminal
|
Barrier terminal
|
|
LCD Display
|
LCD (16X2characters, green
backlight)
|
|
Display Language
|
English
|
|
Data-transfer
port
|
RS232
|
|
Noise[dBA]
|
＜30
|
|
Machinery information
|
|
Ingress
Protection Class
|
IP20 (indoor)
|
|
Mounting
|
Wall
mounting type
|
|
Main dimension(W*D*H)[mm]
|
380*355*150
|
|
Main-device net weight [kg]
|
8.5
|
|
Dump dimension(W*D*H)[mm]
|
440*165*150
|
440*240*150
|
440*240*150
|
550*420*170
|
|
Dump-load net weight [kg]
|
4
|
7
|
7
|
14
|
Product details of MPPT wind solar hybrid charge controller
Assemly of wind charge controller
Project case of MPPT solar charge controller
Package and shippment of solar charge controller
Payment of Wind charge controller
|
|
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
|
FOB
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L
|
|
CIF
|
|
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
|
Amount lower than 5000usd
|
|
|
|
|
7~10days after receiving payment for one container
|
