2.1 Inch 480X480 Resolution Round IPS Touch Panel TFT Screen China Supplier
It is a round IPS high resolution TFT screen product. TFT LCD screen is one of the LCD products with reasonable price, good display effect, wide application and simple development. TFT LCD products have high reliability and high yield, which become the very first choice for many intelligent terminal products.
Here in Jinhua Electronics company we provides a complete and continuously improving TFT LCD solution that able to make GUI development simple, fast and economic. As a custom round IPS TFT screen, we can customize LCD screens and panels for you according to your needs. Y
Small Size TFT Display
Product Parameters
| Display Type |
TFT Display, round shape |
| Display Size |
2.1 Inch |
| View Angle |
IPS/TN |
| Resolution |
480x480 |
| AA |
53.28x53.28mm |
| Backlight Color |
White LED |
| Brightness |
500cd/m2 |
| Interface |
I2C/SPI/MIPI/LVDS/RGB/MCU/UART |
| Control IC |
ST7701S |
| Connector |
FPC |
| Operating Temperature |
-20-70°C |
| Operating Voltage |
2.8V |
| Touch Panel |
Capacitive/Resistive |
| Requirements On Environmental Protection |
ROHS HSF |
Detailed Picture
Features
Δ Wide Viewing Angle
Δ All Kinds Of Emitted Colors And Size
Δ I.C. Compatible
Δ Low Power Consumption
Δ Long Lifespan
Δ RoHS Compliant
Δ High Luminance
Δ Wide Range Working Temperature
Application
Small Size TFT Display could be several kinds of shape such as square, rectangle, round, etc. according to clients' requirement and its application. For round shape TFT display, it is normally used in home appliance such as smart vaccum cleaner, thermostat, water dispensor, etc.
