Novatec Hubs Carbon Road Tubular Wheels Specification
Model
|
RV20T
|
RV24T
|
RV38T
|
RV50T
|
RV60T
|
RV88T
|
|
Material
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
|
Hubs
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
|
Inner/Out Width
|
23mm
|
23mm
|
23mm
|
23mm
|
23mm
|
23mm
|
|
Depth
|
20mm
|
24mm
|
38mm
|
50mm
|
60mm
|
88m
|
|
Rim Type
|
Tubular
|
Tubular
|
Tubular
|
Tubular
|
Tubular
|
Tubular
|
|
Brake System
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
|
Rim Weight
|
250+/-15g
|
290+/-15g
|
330+/-15g
|
385+/-15g
|
420+/-15g
|
525 +/-15g
|
|
ERD
|
606
|
596
|
568
|
544
|
524
|
468
|
|
Weave
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
|
Finish
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
|
Spoke Hole
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
|
Max Spokes Tension
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
|
Max Tyre Pressure
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
|
Max Rider Weight
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
|
Warranty
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
Novatec Hubs Carbon Clincher 23mm Wide Bike Wheels
Model
|
RV24C
|
RV38C
|
RV50C
|
RV60C
|
RV88C
|
|
Material
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
|
Hubs
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
|
Inner/Out Width
|
23mm
|
23mm
|
23mm
|
23mm
|
23mm
|
|
Depth
|
24mm
|
38mm
|
50mm
|
60mm
|
88mm
|
|
Rim Type
|
Clincher
|
Clincher
|
Clincher
|
Clincher
|
Clincher
|
|
Brake System
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
|
Rim Weight
|
390+/-15g
|
440+/-15g
|
480+/-15g
|
525+/-15g
|
625+/-15g
|
|
ERD
|
596
|
569
|
544
|
524
|
468
|
|
Weave
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
|
Finish
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
|
Spoke Hole
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
|
Max Spokes Tension
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
|
Max Tyre Pressure
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
|
Max Rider Weight
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
|
Warranty
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
Novatec Hubs Carbon Tubeless Wheels
Model
|
RV24TL
|
RV38TL
|
RV50TL
|
RV60TL
|
RV88TL
|
|
Material
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
Toray T700
|
|
Hubs
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
|
Inner/Out Width
|
23mm
|
23mm
|
23mm
|
23mm
|
23mm
|
|
Depth
|
24mm
|
38mm
|
50mm
|
60mm
|
88mm
|
|
Rim Type
|
Tubeless
|
Tubeless
|
Tubeless
|
Tubeless
|
Tubeless
|
|
Brake System
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
Rim Brake
|
|
Rim Weight
|
400+/-15g
|
440+/-15g
|
480+/-15g
|
540+/-15g
|
660+/-15g
|
|
ERD
|
598
|
570
|
546
|
526
|
470
|
|
Weave
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
|
Finish
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
Matte/Glossy
|
|
Spoke Hole
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
16/18/20/21/24H
|
|
Max Spokes Tension
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
130 kgf
|
|
Max Tyre Pressure
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
|
Max Rider Weight
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
125 Kg
|
|
Warranty
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
2 Years
|
1. Do you offer compatibility with 9, 10 and 11 speed Shimano/Campy cassette body?
Yes, most hub compatibility with 9/10/11S shimano or compy cassette body.
2. Why do you choose external nipples for the superroad rim?
When adjusting the spoke tension or truing the wheel, you don’t need to remove the tires, tube and rim tape.
