EC-NK201S-PIR 2CH Indoor Wireless NVR Kits
MINI NVR Features：
1.Ethernet cable plug to your home wifi router
2.Fast add device through APP
3.Support 128GB micro SD card
4.Can connect with 2pcs 1080P wireless cameras, MAX 4 PCS
5.Channel indicator led lights
Camera Features：
1.1080P resolution
2.Two way audio
3.Local video storage （on NVR）
4.PIR motion detection
5.IR NIGHT VISION
6.Wirelss pairing adding or AP mode adding
7.Can be used without recorder, by connecting with home wifi
Specification:
|
MINI NVR
|
|
Item
|
EC-NK201S-PIR
|
|
Video/audio input
|
Network video input
|
max 4ch
|
|
Video output
|
Video output
|
Plug to home wifi Router
|
|
Preview
|
APP，CMS
|
|
Video compression
|
Standard H.264
|
|
Video encoding
|
Recording resolution
|
720P/960P/1080P
|
|
Playback
|
1ch (APP)
|
|
Video manage
|
Recording
|
Motion detection recording，auto recording overwriting
|
|
Back up
|
Use card reader to play on PC，make back on APP when viewing playback
|
|
Storage
|
Type
|
1 MicroSD port
|
|
Max
|
128G
|
|
External port
|
Ethernet port
|
1 J45 10M/100M self adaptive Ethernet port
|
|
2 antenna
|
|
Button port
|
2 buttons , one for pairing，1 for reset
|
|
Indicator light
|
P2P LED
|
one P2P LED
|
|
Channel Indicator LED
|
4 CHANNEL LED
|
|
Others
|
Power supply
|
USB DC 5V 1A
|
|
Work Temperature
|
-10℃ to ＋55℃
|
|
Work humidity
|
10％--90％
|
|
Size
|
80x80x27mm
|
|
N.W.
|
80g
|
|
WIRELESS BULLET
|
|
Sensor
|
Sensor
|
1/3" CMOS SENSOR
|
|
Resolution
|
1080P
|
|
Minimum Illumination
|
0Lux (with infrared led)
|
|
Night vision
|
Night vision
|
IR distance 9 METER
|
|
Day vision
|
AUTO SWITCH IR-CUT
|
|
Video
|
Compression
|
H.264
|
|
Resolution
|
1920 x 1080P,640 x 480P
|
|
Audio
|
Input/output
|
Insert mic and speaker(two way audio)
|
|
Audio
|
AAC
|
|
Network
|
WIFI
|
802.11b/g/n;
|
|
WIFI safety classified
|
WEP, WPA, WPA2
|
|
Indicator LED
|
Cable LED
|
GREEN
|
|
Reset button
|
|
For re-code matching
|
|
PIR
|
Included
|
PIR MOTION DETECTION
|
|
Storage
|
Micro SD card
|
MAX 128GB
|
|
Physical feature
|
Work temperature
|
–20°C～50°C
|
|
Work humidity
|
20%～85%; uncondensed
|
|
Storage temperature
|
–20°C～50°C
|
|
Storage humidity
|
20%～85%; uncondensed
|
