Features
|
|
1. Operation speed, decoding ability.
|
|
2. Supports high-performance 1D/2D barcode scanning, which is excellent for illegible barcodes with poor print quality, contamination or distortion
|
|
3. Customer setting : Barcode setting mode, easy to operate
|
|
4. HID USB HID, Virtual COM Port / RS-232 multi-interface optional
|
|
5. Very long depth of field: 0-200mm @ (UPC / EAN 100%, PCS90%).
|
|
6. Equipped with 1280 pixels(H)x 800 pixels(V) megapixel sensor.
|
|
7. All-round automatic induction trigger, able to adapt to various lighting working environments
|
|
Feature
|
|
Light Resource
|
617nm red LED
|
|
Pixel
|
1280 pixels(H)x 800 pixels(V)
|
|
Port/Interface
|
USB (standard)
|
|
Supported Symbologies
|
1D: UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded
|
|
2D:Data Matrix, QR Code, Micro QR Code Aztec Code MaxiCode
|
|
Presicion
|
0.127mm(5mil)@Code 39, PCS=90%
|
|
Depth of scan field
|
0 mm - 160 mm @UPCA -13 mil 100％，PCS 90％
|
|
Operation
|
Manual
|
|
Decode Error Rate
|
0 Error
|
|
Print Contrast Signal
|
≥30° (UPC/EAN 100% , PCS 90%)
|
|
Scan Angle
|
48° (H) x 30° (V)
|
|
Mechanical/ Electrical
|
|
Voltage
|
5VDC±10%
|
|
Current
|
170mA
|
|
Environmetal
|
|
Operation Tempereture
|
0℃~50℃
|
|
Storage Temperature
|
-40℃-70℃
|
|
Humidity
|
5%-95%
|
|
Applicable scope
|
|
|
Comercial POS system(Supermarkets)
|
Warehousing and logistics
|
|
Libraries
|
|
Banks and Telecom
|
|
Transportaion
|
|
Postal service
|
|
Industrial and manufacturing management
|
|
Packing list
|
|
scanner × 1
|
|
|
User's guide × 1
|
|
|
cable × 1
|
|
