Features
|
|
1. Factory direct sale, cheap price and stable scanning
|
|
|
2. Fast and accurate in reading 2D codes
|
|
|
3. Service life of button reaches up to 8 million times.
|
|
|
4. Large capacity battery 2000MAH
|
|
|
Mini Receive
|
|
Applicable scope
|
|
Comercial POS system(Supermarkets)
|
|
Warehousing and logistics
|
|
Libraries
|
|
Banks and Telecom
|
|
Transportaion
|
|
Postal service
|
|
Industrial and manufacturing management
|
|
|
Feature
|
|
Light Resource
|
CMOS
|
|
CPU
|
32 bit high resolution
|
|
Supported Symboligies
|
2D: PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), Chinese Sensible Code
|
|
1D : Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11
|
|
Charging time
|
2~3hour
|
|
Scans per charge
|
30000 times
|
|
Precision
|
≥ 5 mil (0.10mm)
|
|
Decode speed
|
5 in/s(12.7 cm)
|
|
Decode error rate
|
Less than 1/8 million
|
|
Depth of scan field
|
Code 39 40mm~165mm(5mil)
|
|
Ean-13 50mm~365mm(13mil)
|
|
Data Matrix 35mm~115mm(10mil)
|
|
QR Code 35mm-145mm (15mil)
|
|
PDF 417 45mm-115mm(6.67mil)
|
|
Print Contrast Signal
|
≥ 30°
|
|
scan angle
|
Yaw(Skew)45° & Pitch60°
|
|
Working Distance
|
Over 50-150meter
|
|
Battery capacity
|
2000MAH
|
|
Mechanical / Electrical
|
|
Working Voltage
|
3.3 VDC ±5%
|
|
Current
|
working 230mA
|
|
Standby: 3.4mA (RS232）, 54.0mA(USB)
|
|
Rated power consumption
|
186mW
|
|
Environment
|
|
Operating temperature
|
-20°C-45°C
|
|
Storage temperature
|
-20°C-45°C
|
|
Humidity
|
5%-85%
|
