Truck Description:
RHD Dump Trucks can classification by functions : Agricultural dump trucks, mine dump trucks, coal transport dump trucks, dump trucks for construction machinery, sludge dump truck. It consists of a chassis, hydraulic lifting mechanism, cargo box and PTO device.
As the loading compartments can automatically tip and discharge at a certain angle, the time and labor for unloading can be greatly saved.
Advantages:
1. Tipper and Lorry use SHACMAN chassis, quality assurance and no worry for service.
2. Large torque, low rotate speed, and low oil consumption
3. Nice appearance and the best price.
4. Optional RHD or LHD
5. Front hydraulic cylinder
6. With tarpaulin cover avoid to air pollution
|
Dump Tipper SHACMAN (20m³)
|
|
Truck description
|
GVW (kg)
|
25000
|
|
Kerb weight (kg)
|
12500
|
|
Overall
dimension (mm)
|
Length
|
8595
|
|
Width
|
2550
|
|
Height
|
3450
|
|
Box dimension(mm)
|
Length
|
5800
|
|
Width
|
2350
|
|
Height
|
1500
|
|
Chassis
|
Number of axles
|
3
|
|
Allowable Passengers in
cab
|
2
|
|
Air conditioner
|
For option
|
|
Wheel base(mm)
|
3775+1350
|
|
Type of fuel
|
Diesel
|
|
Exhaust/output
|
10338ml/285kw
|
|
Tire specification
|
11.00R20 for option
|
|
Cargo box
|
Material
|
High strength plate
|
|
Thickness
|
Side (mm)
|
6 or changed as request
|
|
Bottom(mm)
|
8 or changed as request
|
|
Other remark
|
Above specification is just for reference, please send us your request
details.
|
|
