300kw 375KVA Silent Diesel Generator With Cummins Engine KTA19-G2
Advantages of Cummins Diesel Engine
1. Genuine Cummins industrial diesel engine
2. Radiator 40/50°C max, fans are driven by belt, with safety guard
3. Genuine stamford. Leroy somer, marathonm, engga alternator,fengfa alternator
4. Choice of manual/auto and AMF control panels and protection systems
5. Digital auto-start panel
6. Anti Vibration Suspension Absorber
7. Dry type air filter, fuel filter, oil filter
8. 8-hour operation base tank
9.Mould case circuit breaker
10. 24V DC start motor and storage battery
11. 24V charge alternator
12. 24V batteries, rack and cable
13. Rippl;e flex echaust pipe, exhaust siphon, flange, and muffler
14. Comply with ISO
15. All generator sets are gone through rigorous testing before beging released to the market place, including 50% load, 75% load,
100% load and all protection function(over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
Engine Specifications:
|
Engine Model
|
KTA19-G2
|
|
Aspiration
|
Turbocharged
|
|
cylinder
|
6
|
|
Bore×Stroke
|
102x120 mm
|
|
Rated speed
|
1500rpm
|
|
Displacement
|
3.9 L
|
|
Compression ratio
|
17.3:1
|
|
Max Power
|
312KW
|
|
Speed Governor
|
Electronic
|
|
Cooling System
|
water-cooled
|
|
Speed Stability (%)
|
≤5%
|
|
Starter Motor
|
24V
|
|
Alternator Parameters
|
|
Alternator brand
|
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
|
|
Prime power
|
310kw
|
|
Frequency/speed
|
50Hz/1500rpm
|
|
Exciter type
|
Single bearing, Brushless, Self-excited
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Voltage regulation NL-FL
|
≤±1%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
|
Controller Panel
|
|
Brand
|
Deepsea/ComAp/SmartGen
|
Function
|
The control module gives digital readouts of:
Generator voltage; Output frequency; Engine speed;
Battery voltage; Engine hours run.
The control module has indicators for failure information:
Overspeed/underspeed; Emergency stop; Low oil pressure; Battery charger failure
High water temperature; Failure to start
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature; Overspeed/underspeed;
Failure to start after three attempts.
|
Product Details
Ai Power products adopts internationally and domestically reputed high-quality engines and alternators including DCEC, CCEC engine, UK famous engine, MTU from Germany, Doosan from South Korea, Stamford, LeroySomer, and Marathon for our industrial diesel generator sets, marine generator, movable generator, lighting towers, generator spare parts and switchgear, power transformers. Those products are featured by personalization, intelligence, environmental protection and high quality. They are widely used in buildings, hospitals, banks, mine, ports, construction, data center, power station and high voltage projects.
Meet the strong, silent type. Cummins Super Quiet generators offer impressive features, plus a totally enclosed body for noticeably quieter performance. Combining quality, portability, reliability, and convenience, a Super Quiet generator is the smart choice whenever quieter is better.Our company only produce water cooled generator, from 5kva to 15kva, we have high quality Japan Kubota, Yanmar, UK Perkins, Cummins and some Chinese local brand etc diesel generator for your choice, The alternator we adopt Leroysomer, Stamford, Marathon etc, all of our products have CE and ISO9001 certificate.
1.What's our power capacity range of generator?
Answer: We can offer the range from 10kva~3000kva genset, diesel generator, gas generator, marine generator.
2. Besides power generator, what's your other product?
Answer: We also provide lighting tower, air compressor, ATS, synchronization system, switchgear, transformer, engine spareparts.
3. What's kind of generator type you produce?
Answer: open generators, silent power generators, super silent genset, trailer genset, movable electric generator, reefer generator.
4.What's your warranty?
Answer: One year or 1000 hours, which one comes first.
5.Can you use our logo?
Answer: Yes, we can use customer's logo instead of ours.
6. Can you accept small order?
Answer: Yes, we can accept trial order.
7. What’s your delivery time?
Answer: Our normal delivery time is 2 to 4 weeks. But if your order is some special engine and alternator, the delivery time will be longer.
