The 3500/65 monitor provides 16 channels of temperature monitoring and
accepts both resistance temperature detector (RTD) and isolated tip
thermocouple (TC) temperature inputs. The monitor conditions these inputs and
compares them against user-programmable alarm setpoints.
The monitor is programmed using the 3500 Rack Configuration Software. You
can configure the 16-Channel Temperature Monitor to accept isolated tip
thermocouples, 3-wire RTD, 4-wire RTD, or a combination of TC and RTD inputs
In Triple Modular Redundant (TMR) configurations, you must install temperature
monitors in groups of 3 adjacent monitors. In this configuration the monitor uses
2 types of voting to ensure accurate operation and to avoid single-point failures
|
3500/65
|
|
|
|
|
|
|
|
Signal
|
|
Accepts from 1 to 16 RTD or
|
|
|
|
isolated tip TC transducer signals
|
|
|
|
|
|
Input Impedance
|
|
Greater than 1 MΩ for each lead input.
|
|
|
|
|
|
Power Consumption
|
|
3 watts nominal
|
|
|
|
|
|
Type E
|
|
-100 °C to +1000 °C
|
|
|
|
(-148 °F to +1832 °F).
|
|
|
|
|
|
Type J
|
|
0 °C to +760 °C
|
|
|
|
(32 °F to +1400 °F)
|
|
|
|
|
|
Type K
|
|
0 °C to +1370 °C
|
|
|
|
(32 °F to +2498 °F)
|
|
|
|
|
|
Type T
|
|
-160°C to +400 °C,
|
|
|
|
(-256 °F to +752 °F).
|
Bently Nevada 3500/65
3500/65 | Bently Nevada | Channel Temperature Monitor
Email:sales3@amikon.cn
You can use software
configuration to set Alert and
Danger setpoints for the value
measured by the monitor. Alarms
are adjustable from 0 to 100% of
full-scale for each measured
value. The exception is when the
full-scale range exceeds the
range of the sensor. In this case,
software will limit the setpoint to
the range of the sensor. Accuracy
of alarms are to within 0.13% of
the desired value. The 3500/65
16-channel temperature monitor
has both under- and over-alarm
setpoints.
