Media Type:   Single-Mode Fiber (SMF)

TX Wavelength:  1550 nm.

RX Wavelength:  1550 nm.

Minimum Optical Budget:  23 dB

Maximum Distance:  80km

Supported Data Rate:  1.24-11.32Gbps

Supported Applications:

 Gigabit Ethernet (1.25 Gbps), 10G Fiber Channel (10.52 Gbps), 8G Fiber Channel (8.5 Gbps), 4G Fiber Channel (4.25 Gbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), , STM-64 (9.95Gbps), ODU0 (1.244Gbps), ODU1 (2.498Gbps), ODU2 (10.037Gbps), ODU2e (10.399Gbps), OTU1 (2.66Gbps), OTU2 (10.70Gbps), OTU1f (11.27Gbps), OTU2f (11.32Gbps), OTU1e (11.049Gbps), 10G Ethernet (10.31Gbps),OTU2e (11.095Gbps),STM-16 (2.488 Gbps)

DDM/DOM:    Support

Temperature Range:  Standard 0°-70°C

Connectors:   Double LC

Tx Wavelength Bandwidth:  37 nm (1528-1565 nm)

Rx Wavelength Bandwidth:  37 nm (1528-1565 nm)

Minimum Transmitting Power: 0 dB

Maximum Transmitting Power: 4 dB

Receiver Sensitivity: -23 dBm

Receiver Overload: -7 dBm

Dispersion: 1600 ps/nm

Transmitter Type: EML Laser

Receiver Type: APD Photodiode

Power: +3.3V single power supply

Chipset: MAXIM, MINDSPEED, SEMTECH

Compliance: CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8077i XFP MSA Rev.4.5, RoHS

Transceiver Type: XFP
