4-Bolt Flange Bearing Units UCFS3

UCFS300 Heavy duty,Pilot on the back of housing,Wider inner ring bearing,Setscrew locking,Cast gray iron housing .

Cast ductile iron housing available upon request.



Facebook Twitter Pinterest LinkedIn 分享

Flange housing UCFS306

Unit No. Shaft Dia Dimensions (mm) Bolt Size (mm) Weight (kg)
d L J A2 A1 A H H1 N D1 S Z
(in) (mm)
UCFS305  25 110 80 9 22 29 7 13 16 80 15 32 M14 1.3
UCFS305-14  7/8    110 80 9 22 29 7 13 16 80 15 32 M14 1.3
UCFS305-15  15/16    110 80 9 22 29 7 13 16 80 15 32 M14 1.3
UCFS305-16 1   110 80 9 22 29 7 13 16 80 15 32 M14 1.3
UCFS306  30 125 95 10 24 32 8 15 16 90 17 36 M14 1.9
UCFS306-18  1-1/8    125 95 10 24 32 8 15 16 90 17 36 M14 1.9
UCFS306-19 1-3/16   125 95 10 24 32 8 15 16 90 17 36 M14 1.9
UCFS307  35 135 100 11 27 36 9 16 19 100 19 40 M16 2.4
UCFS307-20  1-1/4    135 100 11 27 36 9 16 19 100 19 40 M16 2.4
UCFS307-21  1-5/16    135 100 11 27 36 9 16 19 100 19 40 M16 2.4
UCFS307-22 1-3/8   135 100 11 27 36 9 16 19 100 19 40 M16 2.4
UCFS308  40 150 112 13 30 40 10 17 19 115 19 46 M16 3.3
UCFS308-24  1-7/8    150 112 13 30 40 10 17 19 115 19 46 M16 3.3
UCFS308-25 1-15/16   150 112 13 30 40 10 17 19 115 19 46 M16 3.3
UCFS309  45 160 125 14 33 44 11 18 19 125 22 49 M16 4.0
UCFS309-26  2   160 125 14 33 44 11 18 19 125 22 49 M16 4.0
UCFS309-27  2-1/8    160 125 14 33 44 11 18 19 125 22 49 M16 4.0
UCFS309-28 2-3/16   160 125 14 33 44 11 18 19 125 22 49 M16 4.0
UCFS310  50 175 132 16 36 48 12 19 23 140 22 55 M20 5.3
UCFS310-30  1-7/8    175 132 16 36 48 12 19 23 140 22 55 M20 5.3
UCFS310-31 1-15/16   175 132 16 36 48 12 19 23 140 22 55 M20 5.3
UCFS311  55 185 140 17 39 52 13 20 23 150 25 58 M20 6.2
UCFS311-32  2   185 140 17 39 52 13 20 23 150 25 58 M20 6.2
UCFS311-34  2-1/8    185 140 17 39 52 13 20 23 150 25 58 M20 6.2
UCFS311-36 2-3/16   185 140 17 39 52 13 20 23 150 25 58 M20 6.2
UCFS312  60 195 150 19 42 56 14 22 23 160 26 64 M20 7.2
UCFS312-36  2-1/4    195 150 19 42 56 14 22 23 160 26 64 M20 7.2
UCFS312-38  2-3/8    195 150 19 42 56 14 22 23 160 26 64 M20 7.2
UCFS312-39 2-7/16   195 150 19 42 56 14 22 23 160 26 64 M20 7.2
UCFS313  65 208 166 15 40 58 18 22 23 175 30 60 M20 8.9
UCFS313-40 2-1/2   208 166 15 40 58 18 22 23 175 30 60 M20 8.9
UCFS314  70 226 178 18 43 61 18 25 25 185 31 65 M22 11
UCFS314-44 2-3/4   226 178 18 43 61 18 25 25 185 31 65 M22 11
UCFS315  75 236 184 21 48 66 18 25 25 200 32 71 M22 13
UCFS315-48 3   236 184 21 48 66 18 25 25 200 32 71 M22 13
UCFS316   80 250 196 18 48 68 20 27 31 210 34 70 M27 15
UCFS317  85 260 204 24 54 74 20 27 31 220 40 80 M27 17
UCFS317-52 3-1/4   260 204 24 54 74 20 27 31 220 40 80 M27 17
UCFS318  90 280 216 24 56 76 20 30 35 240 40 80 M30 21
UCFS318-56 3-1/2   280 216 24 56 76 20 30 35 240 40 80 M30 21
UCFS319  95 290 228 39 74 94 20 30 35 250 41 101 M30 25
UCFS319-60 3-3/4   290 228 39 74 94 20 30 35 250 41 101 M30 25
UCFS320  100 310 242 39 74 94 20 32 38 260 42 105 M33 30
UCFS320-64 4   310 242 39 74 94 20 32 38 260 42 105 M33 30
UCFS322   100 340 266 35 71 96 25 35 41 300 46 106 M36 39
UCFS324   120 370 290 35 80 110 30 40 41 330 51 110 M36 54
UCFS326   130 410 320 35 85 115 30 45 41 360 54 116 M36 71
UCFS328   140 450 350 45 95 125 30 55 41 400 59 131 M36 100
