Traction type: 6x4
Driving type: LHD
Cabin:
North Benz long cabin, one sleeper, Air Conditioner
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
fuel level)
Headlight, Sun protection on cabin.
Engine:
Engine brand: Weichai
Engine model: WP12.480 480hp
Emission standard: EURO3( high-pressure common rail )
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
with water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 11.596 liters
Max. output: 480hp@353kW
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm):126/155
Clutch:
Clutch:Φ430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 12 speeds(12JS200T),manual,12-forward and 2 reverse speeds
Steering:
TAS85
Brake system:
Double-circulate brake system with ABS
Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Mercedes Benz Technology, Double-shoe pneumatic brake, ductile casting casing, with
hub redactor, double reduction driving axle ,Ratio:1:5.921(option5.263,6.733)
Frame: Strengthened frame 317x70x8.5+7+12mm(E380TM)
