Specification
LIGHT
SOURCE
Lamp: Osram SIRIUS HRI 461W
CT: 7000 K
Lifespan: 2,000H
OPTICS
Zoom range: 7°–40°
High precision glass
optic system
Improved optics and
flat beam field
COLORS
CMY+CTO(3200K) color mixing
system
1 Color wheel: 10color+open
Half-color effect,
linear color change, bidirectional rotating rainbow effect
GOBOS
1 Static gobo: 13
gobos+open, shakable and bi-directionally rotatable at variable speeds
1 Rotating gobo: 8
interchangeable gobos +open, shakable and bi-directionally rotatable at
variable speeds
MOVEMENT
Pan movement: 540° optional (16 bit )
Tilt movement: 270°(16
bit )
Advanced moving system: auto repositioning, fast, quiet and smooth
FEATURES
Frame: 4 pcs 8-point moveable framing shaping sheets, creat different- size geometrical patterns, patterns 90°revolvable
Aperture: mechanical linear aperture, changeable light spot size
2 Prisms: 8-facet+16-facet,
bi-directionally rotatable at variable speeds
Frost: 1 frost filter,
soft and natural wash effect
Strobe: mechanical
shutter , variable from 1-20Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable
Focus: motorized
linear focus
Zoom range:
Beam mode 7°- 20°
Spot mode 9°- 40°
Wash mode 15°- 45°
DISPLAY
2.8 inch full color
touch LCD screen, show customer logo
15 second standby auto
lock
SOFTWARE
Control mode: DMX512,
master-slave, auto-run, sound activate
Channel: 35CH
Run time of lamp and
fixture record
OTHER SPEC
Fixture and lamp usage
time display
Highly positioning
precision
Built-in analyzer for
easy fault finding, error messages
Input signal isolating
protection
Auto thermal
protection circuit
Housing: high
temperature UV resistant ABS
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 600W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 42*33*60cm
Packing dimension:
46x42x69cm (Carton)
90x41x82cm(2 in 1 flightcase)
Net Weight: 23.5kg
Gross Weight:
26kg(Carton)
75kg(2 in 1 flightcase)
