500W Dimmable Stadium Led Exterior Flood Lighting Fixtures
12+ Years Experience China Exterior Led Light Manufacturer provide Kinds of high quality Led Stadium Flood Light from 50W to 1500W, at Different Housing with Factory directly sale Competitive Price,5 Years Warranty.
All Flood Lights use Original Epistar, Bridgelux, Philips, Osram, Nicha, CREE LED chip. Meanwell or other high quality drivers.
How to choose Led Stadium Flood Lights Wattage -
It is very important to get the right brightness and coverage for the application.Our Engineers can provide you the professional Dialux if you can provide the projects drawing.
Each flood light is different, with some running more efficiently than others. With most LED products you should check the lumens but not the wattage. LED flood lights can jump large amounts each wattage, so they will roughly all the do the same job,and what's more can save more energy. A normally guide would be the following:
10 x 10 meter area - 10w LED Flood light
20 x 20 meter area - 30w LED Flood light
30 x 30 meter area - 50w LED Flood light
50 x 50 meter area - 100w LED Flood light
100 x 100 meter area - 200w + Flood lights
Specifications:
|
Model:
|
SED-TFDB-500W
|
|
Lumens Per Watt:
|
165 lumens per watt
|
Wattage:
|
500w
|
|
Voltage:
|
AC90-305V
|
|
Frequency:
|
50-60 hz
|
|
Power Factor:
|
>0.90
|
|
Color Temperature:
|
2700~6500K
|
|
THD:
|
10% Max
|
|
Life Time:
|
>50,000 hours
|
|
Led Chip:
|
Philips SMD3030 Serial and Parallel 7S*49P 343*4 Pcs
|
|
CRI:
|
>80
|
|
Beam Angle:
|
25°/45°/60°/90°
|
|
Storage Temp:
|
–30 ~ 55°C
|
|
IP Rating:
|
IP67
|
|
Dimmable:
|
0-10V or Phase Cut | Da Li Optional
|
|
Housing:
|
Black Finish/Aluminum die-cast housing
|
|
Mounting:
|
Hook / Eye Mount (Standard), pendant mount ,surface mount
|
|
Product Size:
|
438*495*128mm
|
|
Net Weight:
|
12.5KG
|
|
Packaging Size:
|
470*530*150mm
|
|
Quantity/Carton:
|
1PCS/Carton
|
|
Gross Weight:
|
13.5KG
|
|
Warranty:
|
5 years
|
|
Driver:
|
Mean Well Or CE Driver Optional
|
Features:
-
Modular lens design easily repair
-
Anti Glare,Beautiful housing
-
Kinds of Beam Angle,light weight with good heat sink
-
led outdoor flood lights have variety of installation methods, rods can be formulated rod, and the angle is adjustable.
-
Pure aluminum Material,Anti-rust
LED Flood Light Common Application:
1. Replace traditional high pressure sodium lamp or metal halide lamp.
2. Widely used in Parking Lot Lighting, Sports Stadium lighting, Billboard lighting, Outdoor and Indoor Area Lighting, Warehouses and Security areas etc.
