50m Temporary Warehouse Tent
Superb Tent is proud to announce that we are making 50m width of warehouse tent.
This type of tent will have the required space for your storage. The materials are of high standard and the end product meets all the standards. The pvc is treated against excess heat and is also waterproof.
The aluminum bars used meet this type of tent, because of Its use. The tent is also strong to resist heavy blowing winds.The tent is designed to meet ones specification , keeping in mind the available space.
Available sizes:
● Clear span available from 3m to 60m.
● Length: adjustable by 3m unit (SS & WS series) or 5m unit (for other series).
Frame:
● No maintenance required.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
● Modular character for diverse combination and expansion.
Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
The Specification of 50m Temporary Warehouse Tent:
|
Type
|
Span
(m)
|
Side
height (m)
|
Ridge
height (m)
|
Bay
Distance (m)
|
Roof
Pitch
|
Longest
Component (m)
|
Wind
Load (km/h)
|
|
XLS20/4-5
|
20
|
4
|
7.2
|
5
|
18°
|
10.7
|
100
|
|
XLS25/4-5
|
25
|
4
|
8
|
5
|
18°
|
10.7
|
100
|
|
XLS30/4-5
|
30
|
4
|
8.9
|
5
|
18°
|
10.7
|
100
|
|
XLS40/4-5
|
40
|
4
|
10.5
|
5
|
18°
|
11.5
|
100
|
|
Main
frame Profile
|
300x120x5mm（4-channel)
|
|
Eave
Connection
|
Hot-dip
Galvanized Twin Steel Plate
|
|
Roof
Fixing
|
Bar
Tension
|
|
Frame
Material
|
Hard
Pressed Extruded Aluminum 6061/T6
|
|
Cover
Material
|
Double
PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
