Feature:
Good high temperature performance
Safe Lithium Iron Phosphate Technology
High energy density and conversion efficiency
Life Span: 2000 cycle times
Environmental Friendly, without any heavy metals
Complete with Battery Management System built-in
Can use AC and solar chargers for this system
Low self discharge rate
Easy installation, can be in standard cabinet or be wall-mounted
Built-in automatic protectionfor over-charge, over-discharge&over-temperature conditions
High energy density 120-130kwh/kg,evenhigh discharge rate , while maintaining high energy capacity.
Increased Flexibility : Modular design enables deployment
Good High Rate Discharging and Excellent Stability
Intelligent chip design, excellent battery's storage capacity
Applications：
The battery is applicable for industrial , commercial or residential purposes
Battery Modules or Units are connected from Wh up to Mwh for renewable energy system
Energy Storage System
Solar Energy Storage
Solar Street Lighting
Electric Vehicle ( EV)
Medical
Telecom
Robotic
UPS
Item
|
Specification
|
Type
|
lithium battery
|
Voltage
|
51.2V
|
Rated capacity
|
100Ah (0.2C/25°C) (Min:98Ah)
|
Energy
|
4200wh
|
Operating voltage range
|
42V- 58.4V (Typical:51.2V)
|
Charging voltage
|
56.0V±1.0V
|
Discharge cut-off voltage
|
42V±2.0V
|
Charging current
|
20A
|
Charging current(Max.)
|
30A
|
Continuous Current
|
50A
|
Discharge current(Max.)
|
100A
|
Months Self Discharge
|
≤3.5%
|
