59L rolling shutter motor tubular motor series with hand chain

1. Limit accuracy, easy to set
2. Smooth operation, low noise
3. Compact structure, easy to install
4. The stroke head is equipped with a hand-held device for easy opening and closing of the door
5. Good concealment, take up a small space

HDM59L-100/8

Input Voltage: DC 24V

Rated torque: 100N.m

Diameter: 59

Rated speed: 8r/min

Compare with traditional tubular motor:

1. transfer method

59L: Outer tube drive

Traditional: Inner shaft of motor

2. Transmission performance

59L: When power-off or failure, you can easily pull the hand chain to drive the door up or down. If the motor or deceleration site occurred stuck or other causes of failure, regardless of the door to stay in any position, can be driven by hand chain.

Traditional: When power-off or failure,If the door is large, you will feel strenuous.  If the gear box failure (stuck), hand chain can not open the door.
