MODEL
|
1KW
|
1.5KW
|
2KW
|
3KW
|
4KW
|
5KW
|
6KW
|
|
Default Battery System Voltage
|
12VDC
|
24VDC
|
12VDC
|
24VDC
|
12VDC
|
24VDC
|
12VDC
|
24VDC
|
24VDC/48VDC
|
24VDC/48VDC
|
24VDC/48VDC
|
|
INVERTER OUTPUT
|
Rated Power
|
1KW
|
1.5KW
|
2KW
|
3KW
|
4KW
|
5KW
|
6KW
|
|
Surge Rating (20ms)
|
3KVA
|
4.5KVA
|
6KVA
|
9KVA
|
12KW
|
15KW
|
18KW
|
|
Capable Of Starting Electric Motor
|
1HP
|
1HP
|
1HP
|
2HP
|
2HP
|
3HP
|
3HP
|
|
Waveform
|
Pure sine wave/ same as input (bypass mode)
|
Pure sine wave/ same as input (bypass mode)
|
|
Total Harmonic Distortion(THD)
|
<3%
|
|
Nominal Output Voltage RMS
|
100V/110V/120VAC 220V/230V/240VAC(+/-10% RMS)
|
|
Output Frequency
|
50Hz/60Hz +/-0.3 Hz
|
50Hz/60Hz +/-0.3 Hz
|
|
Inverter Efficiency(Peak)
|
>88%
|
>88%
|
|
Line Mode Efficiency
|
>95%
|
>95%
|
|
Power Factor
|
0,8
|
1,0
|
|
Typical Transfer Time
|
10ms(max)
|
10ms(max)
|
|
AC INPUT
|
Voltage
|
100V/110V/120VAC 220V/230V/240VAC(+/-10% RMS)
|
|
Selectable Voltage Range
|
96~132VAC 155~280VAC(For Personal Computers)
|
96~132VAC/155~280VAC(For Personal Computers)
|
|
Frequency Range
|
50Hz/60Hz (Auto sensing) 40-80Hz
|
50HZ/60HZ (Auto sensing) 40-80Hz
|
|
BATTERY
|
Rated Input Voltage Range
|
8.0-80.0VCC
|
|
Minimum Start Voltage
|
10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, )
|
20.0VDC~21.0VDC /40.0VDC~42.0VDC
|
|
Low Battery Alarm
|
10.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )
|
21.0VDC+/-0.6V /42.0VDC+/-1.2V
|
|
Low Battery Cutoff
|
10.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )
|
20.0VDC+/-0.6V /40.0VDC+/-1.2V
|
|
High Voltage Alarm
|
16.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )
|
32.0VDC+/-0.6V /64.0VDC+/-1.2V
|
|
High Battery Voltage Recover
|
15.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )
|
31.0VDC+/-0.6V / 62.0VDC+/-1.2V
|
|
Idle Consumption-Search Mode
|
<25W when power saver on
|
<50W when power saver on
|
|
AC CHARGER
|
Output Voltage
|
Depends on battery type
|
Depends on battery tvpe
|
|
Charger AC Input Breaker Rating
|
10A
|
30A
|
30A
|
30A
|
40A
|
|
Overcharge Protection S.D.
|
15.7VDC for 12VDC mode (*2 for 24VDC, )
|
31.4VDC/62.8VDC
|
|
Maximum Charge Current
|
35A
|
20A
|
45A
|
25A
|
65A
|
35A
|
75A
|
45A
|
65A
|
35A
|
70A
|
40A
|
75A
|
50A
|
|
Battery Temperature Compensation
|
Automatic with temperature sensor (RTS)
|
BYPASS
& PROTECTION
|
Input Voltage Waveform
|
Sine wave (grid or generator)
|
Sine wave (grid or generator)
|
|
Nominal Input Frequency
|
50Hz or 60Hz
|
50Hz or 60Hz
|
|
Overload Protection (SMPS Load)
|
Circuit breaker
|
Circuit breaker
|
|
DC Current Inverse Protection
|
Bypass diode
|
Bypass diode
|
|
Output Short Circuit Protection
|
Circuit breaker
|
Circuit breaker
|
|
Bypass Breaker Rating
|
10A
|
15A
|
30A
|
30A
|
40A
|
|
Max Bypass Current
|
30Amp
|
40Amp
|
|
SOLAR CHARGER
|
Maximum PV Array Power
|
600W
|
1200W
|
600W
|
1200W
|
600W
|
1200W
|
600W
|
1200W
|
1600W
|
3200W
|
1600W
|
3200W
|
1600W
|
3200W
|
|
Maximum PV Charge Current
|
40A
|
60A
|
|
DC Voltage
|
12V/24V atuo work
|
24V/48V atuo work
|
|
MPPT Range @ Operating Voltage
|
16~100VDC
|
32~145VDC @ 24V / 64~145VDC @ 48V
|
|
Maximum PV Array Open Circuit Voltage
|
100VDC
|
145VDC
|
|
Maximum Efficiency
|
>90%
|
>98%
|
|
Standby Power Consumption
|
<2W
|
<2W
|
|
MECHANICAL SPECIFICATIONS
|
Mounting
|
Wall mount
|
Wall mount
|
|
Dimensions (W*H*D)
|
460*277*192mm
|
597x277x198mm
|
|
Net Weight (Solar CHG) kg
|
18,3
|
22
|
23,5
|
23
|
28
|
27
|
39,6
|
48,6
|
48,6
|
|
Shipping Dimensions(W*H*D)
|
554*360*300mm
|
743*372*312mm
|
|
Shipping Weight (Solar CHG) kg
|
21,9
|
24,8
|
26,5
|
25,6
|
31
|
30
|
43,3
|
53
|
53
|
|
OTHER
|
Application
|
Off grid power system
|
|
Operation Temperature Range
|
0°C to 40°C
|
|
Storage Temperature
|
-15°C to 60°C
|
|
Audible Noise
|
60dB MAX
|
|
Display
|
LED+LCD
|
|
Internet Standard
|
TCP/IP,DNS,SMTP,FTP,DHCP,NTP
|
|
Communication Protocol
|
MODBUS TCP/IP, dnp3, 104 from IEC 61850
|
|
Loading(20GP/40GP/40HQ)
|
460pcs / 920pcs / 1060pcs
|
320pcs / 640pcs / 750pcs
|
