EC-F01X H.265 Full View Camera
EC-F01X 360 Fisheye Camera can accept insert up to 64G SD card to storage the video, and also the H.265 compression can help you to save the space and storage quickly.
The demand for non-blind video surveillance systems in the market is getting more and more intense. The Panoramic Fisheye Full View Camera is to achieve panoramic surveillance. Its appearance can eliminate blind spots in the true sense and ensure the reliability and integrity of videos. It is an important technology to the users even the society.
Features:
1. 3D perspective
2. 360° Panoramic Fish Eye Lens, No Blind Spot
3. H.265/H.264/MJPEG, Mobile phone, UPNP
4. Support TF card/Wireless
5. Motion detection
6. Support two-way voice intercom
7. P2P Cloud Services
8. Plug and play
9. Remote control
10. Infrared night vision
11. Inter Audio ,Inter WIFI
12. Support Multi-user online access
13. Power Supply:5V2A
Specification:
|
Video
|
|
|
Video Compression
|
H.265/H.264/MJPEG
|
|
Day /
Night Mode
|
Color
during day, switches to B&W at night
|
|
Maximum
Frame Rate
|
12fps@2592*1944
|
|
Maximum
Streams
|
3
Simultaneous Streams
|
|
Camera
|
|
|
Sensor
|
1/3"5.0 Mega Pixel Color CMOS sensor
|
|
Max.
Resolution
|
2592*1944(5 Megapixels)
|
|
Lens
|
360°
fish-eye Lens
|
|
ICR
Control
|
Yes
|
|
Viewing
Angle
|
360°
|
|
Min.
Illumination
|
0.08Lux
|
|
PTZ
|
|
Pan/Tilt
Range
|
N/A
|
|
Night Vision
|
|
Night
Vision Distance
|
up to
10M/33ft
|
|
Illumination
|
Array LED
|
|
Audio
|
|
|
Audio
Input
|
1 Built-in
Microphone
|
|
Audio Output
|
1 Built-in
Speaker
|
|
Compression
|
G.711
|
|
Network
|
|
|
Network
Type
|
TCP/IP,
ICMP, HTTP, HTTPS, DHCP, DNS, DDNS,
RTP, RTSP, PPPoE, NTP, UPnP, SMTP, P2P
|
|
WIFI
|
IEEE
802.11b/g/n, 2.4GHz band
|
|
ONVIF
Support
|
ONVIF
Profile S
|
|
P2P
|
Yes,
|
|
Maximun
Online Visitor
|
3 visitors
simultaneously
|
|
Alarm
|
|
|
Motion
Detection
|
Yes
|
|
Alarm I/O
|
optional
|
|
General
|
|
|
External
Storage
|
MicroSD
Card (Capacity supports up to 64G)
|
|
Indoor /
Outdoor
|
Indoor
|
|
Operating
Temperature
|
0°C ~ 50°C
|
|
Power
Consumption
|
DC 5V/1A
|
|
Dimension
(LxWxH)
|
110 x 112
x 122mm
|
|
Weight
|
500g
|
|
mobile phone
|
|
Operating
System
|
iOS&android
|
|
Package Content
|
|
contains
|
EC-F01X 360°Panoramic camera Type-C Cablle(optional)
Quick
Installation Guide
Power
Adapter
Screw Kit
|
