6-18W Double Color LED Lamp Panel

Feature:
1. Aluminum Fins for better heat dissipation + Glass
2. With quality famous-brand LED Inside ( Epistar LED )
3. Lifetime: 50000 hrs(17 years with 8 hours per day)
4. Proprietary design for excellent thermal management and lumen maintenance.
5. Wide voltage and constant current design
6. The products are in accordance with CE, RoHS, and FCC testing standards.
7. Warranty: 2 years
8. Without UV, infered oor mercury.

Facebook Twitter Pinterest LinkedIn 分享

Description

6-18W Double Color LED Lamp Panel

Model:	ZY-PL02
Input Power:	18+6W
Voltage:	85-265V
Fixing	Embeded Mounted or Surface Mounted
Luminous Flux:	>1440lm
CRI:	Ra 85-90
Beam angle:	30 degree and 60 degree
Dimension:	225mm*225mm
Net Weight:	550g
Materials:	Aluminum body+Glass
Lifetime:	>50000H
Warranty:	2 Years
Color Temperature	2700K-6500K

Parameters:

Input voltage: AC85-265V 50-60Hz
Power: 6W, 12W, 18W
Lighting Color: Warm White & nature White &cold white
Shell Color: White, Meterial: AL + Glass
LED: EPILEDS SMD5730
Color Temp: 3200K /6500K
Lumen: 1440Lm
Outer Diameter: 225mm*225mm
Cut Hole: 200mm
Weight: N. G: 480/550g

Box size: 270*230*30mm

Category : LED Panel Light

Adapter PARA:

Input: AC90-265V

Output: DC12-22V 300mA± 5%

TC: 75 degree TA: 50 degree (max)

30/45/60/120 degree beam angle

Application:

Can be used in indoor places.

Widespread use in commercial building, hotel, restaurant, Night Club, etc.

Other place like office, tower, subway station, Bus & Train station, factories, stadiums, wharfs, tunnel, etc.
