Specification

LIGHT SOURCE

Lamp: 1 pcs 60W LED

CT: 8000K

Lifespan: 50,000H

OPTICS

Beam: 14°

High precision glass optic system

Improved optics and flat beam field

COLORS
1 Color wheel: 9 color+open

Half-color effect, linear color change, bidirectional rotating rainbow effect

GOBOS

1 Static gobo wheel: 8 gobos+open, shakable and bi-directionally rotatable at variable speeds

I Rotating gobo wheel: 6 gobos+open, shakable and bi-directionally rotatable at variable speeds

MOVEMENT
Pan movement: 540° optional (16 bit )

Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth

FEATURES

Prism: 3-facet, bi-directionally rotatable at variable speeds

Strobe: electronic strobe, variable from 1-10Hz or random
Dimming: electronic dimmer 0-100% linearly adjustable

Focus: motorized linear focus

DISPLAY

Blue LCD screen

15 second standby auto lock

SOFTWARE

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 16 CH

Run time of lamp and fixture record

OTHER SPEC

Fixture and lamp usage time display

Highly positioning precision

Built-in analyzer for easy fault finding, error messages

Input signal isolating protection

Auto thermal protection circuit

Housing: high temperature UV resistant ABS

POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 110W@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 25x26x36cm

Packing dimension:

                         35x34x45cm(Carton)

                         58x60x48cm(4 in 1 flightcase)

Net Weight:        7.3kg

Gross Weight:

                         9kg(Carton)
