• Multi-axis collaborative robot joints
• Automated sorting and conveyor pulleys
• Precision rotary actuators and sensors
• Robotic gripper rotation units

• Centrifuge rotor support systems
• Diagnostic imaging table height adjusters
• Laboratory fluid agitation mechanisms
• Specialized surgical lighting pivots

• Food-grade filling and capping stations
• Labeling machine roller supports
• Heat-sealing mechanism guides
• Automated weighing and dosing systems

• Large-scale gimbal stabilization platforms
• Satellite dish azimuth/elevation drives
• Remote-operated camera crane joints
• Precision optical grinding equipment

01. Ultra-Thin Radial Cross-Section

The primary advantage of the 6711-2RS is its extremely low-profile design. By maintaining a cross-section of only 6.5mm (radial height), it allows for a significantly larger shaft diameter within a compact outer housing. This enables engineers to design stiffer, more hollow-shaft systems for routing cables or fluids without increasing the machine's overall bulk.

02. Enhanced 2RS Contact Sealing Technology

Unlike shielded bearings, the 2RS configuration utilizes reinforced rubber seals that make physical contact with the inner ring. This creates a highly effective seal that excludes fine dust and prevents grease leakage. This feature makes the 6711-2RS the ideal choice for environments where cleanliness and long-term lubrication retention are prioritized over maximum theoretical speed.

03. High Structural Rigidity vs. Low Weight

Despite its slender dimensions, the 6711-2RS is manufactured from high-density GCr15 chrome steel, providing excellent fatigue resistance and structural integrity. The design minimizes rotational inertia, allowing for rapid acceleration and deceleration in servo-controlled applications, which is vital for high-speed pick-and-place automation.

Interchange Part Numbers

Directly compatible with industry-standard thin-section bearings:

• SKF: 61711-2RS1 / 6711-2RS
• NSK: 6711DDU
• FAG: 6711.2RSR
• NTN: 6711LLU
• KOYO: 6711-2RS

Design & Configuration

The 6711-2RS comes pre-filled with high-performance lithium-based grease as standard. While the rubber seals provide maximum protection, we also offer the 6711-ZZ (metal shields) for higher-speed applications with lower friction requirements. For specialized industries such as food processing or chemical handling, stainless steel (AISI 440C) versions can be supplied upon request to ensure maximum corrosion resistance.

"The 6711-2RS provides the critical sealing and space-saving geometry required for the next generation of precision automation and medical technology."
