Specifications apply to these Ultra3000 drive models:

• SE indicates the 2098-DSD-xxx-SE SERCOS interface drive

• DN indicates the 2098-DSD-xxx-DN DeviceNet interface drive

• X indicates the 2098-DSD-xxxX indexing drive

• X-DN indicates the 2098-DSD-xxxX-DN indexing DeviceNet interface drive

    While circuit breakers offer some convenience, there are limitations for their use. Circuit breakers do not handle high current inrush as well as fuses.

    Make sure the selected components are properly coordinated and meet acceptable codes including any requirements for branch circuit protection. Evaluation of the short-circuit available current is critical and must be kept below the short-circuit current rating of the circuit breaker.

   This section contains dimensions for the Ultra3000 digital servo drives (X indicates indexing, -SE indicates SERCOS interface, -DN indicates DeviceNet interface, and X-DN indicates indexing DeviceNet interface).
