8pcs 16pcs Solar Modules Pole Ground Mounting System
Jesfer solar panel pole mounting kit can be rotated to the best position ,which the foundation is concrete with pre-buried bolt ,and the array of solar panels on each pole can be turned to any of five angles:10°,20° ,30°,40°,5° or according customer’s requirements to maximize power generation.
System Structure
Solar Pole Structure
Technical Parameters
-
Installation site:Open Field
-
Max wind speed:up to 60m/s
-
Max snow load:up to 1.4KN/㎡
-
Tilt Angle:10-60 degree
-
Building Height:up to 20m
-
Pole Material:Galvanized Steel
-
Ground Clearance:200-2000mm
-
Applicable Solar Module:Framed or Frameless
Feature
1.Post cap adjustable according to the gergraphical location demand
2.1-16 solar modules can be supported by the pole in a strong and secure way
3.Widely applications in solar pumps,home solar system and open field ground solar project.
Components Details
 Rail 45
Specification：L*45*45
Standard Length：3100mm,4100mm,5100mm
|
 Splice for Rail 45 Kit
Specification：L260mm
Components：Splice for Rail 45,Hexa Self-Tapping Screw
With EPDM Washer ST6.3*19
|
 Inter Clamp Kit
Components: Inter Clamp ,Cross Module
Spring Washer M8
Hexagon Socket Head Bolt
|
 End Clamp Kit
Components:End Clamp,Cross Module,Spring Washer M8
Hexagon Socket Head Bolt
|
 Girder
Specification：L2000-3000mm
Material:Steel Q235B(hop dip galvanized)
|
 C Clamp Kit
Components:C Clamp,Nut M8,Washer M8
Spring Washer M8,Hexagon Socket Bolt
|
 Beam & Beam Connector
Specification:Beam：L2800-3500mm Fastener：L350
Material :Q235B(Hot-Dip Galvanized)
|
 Quadrate Post & Post Connector
Specification：Post：L2500-3500mm
Material：Q235B(Hot-Dip Galvanized)
|
|
Adjustable Pole & Adjustable Pole Jointer
Specification:Adjustable Pole：L410 Connector：L186
Material:Q235B(Hot-Dip Galvanized)
|
|
Note
We can do customization for different conditions for the numbers of solar modules pole mount ,the length of the purlin, beam .
