9,000 Isuzu transport Fuel Tanker Truck

Fuel Oil Tank Truck 12600L ISUZUChassis Transport Fuel Tanker Truck 4x2,9,000 Isuzu transport Fuel Tanker Truck,Customer Isuzu fuel tanker trucks



9,000 Isuzu transport Fuel Tanker Truck

9,000 Isuzu transport Fuel Tanker Truck



Description:

ISUZU Fuel Tank Trucks (also called Isuzu oil refueling truck, diesel truck, Isuzu petrol fuel tank, NPR fuel dispensing tanker, oil refueler truck Isuzu trucks, light fuel tank truck, Isuzu fuel oil tanker, oil tank for truck) is used to transport oil, diesel, gasoline, kerosene,


Technical drawings:

5 cubic meter Fuel tank truck Isuzu



The Isuzu fuel tank transportation series, as to the whole tank truck, usage for transport the gasoline, light diesel oil, petroleum and other non-corresive fuel properties, rarely impact the damage for oil pump, generator, refullering gun,etc.



Overview of ISUZU Fuel Tank Truck:

 5 cubic meter Fuel tank truck Isuzu    5 cubic meter Fuel tank truck Isuzu

 5 cubic meter Fuel tank truck Isuzu    5 cubic meter Fuel tank truck Isuzu

 5 cubic meter Fuel tank truck Isuzu    5 cubic meter Fuel tank truck Isuzu

Fuel Tank Body Work:

5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu




Details picture of ISUZU Fuel Tanker Truck


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


5 cubic meter Fuel tank truck Isuzu


Optional Equipment of ISUZU Fuel Tanker Truck


 5 cubic meter Fuel tank truck Isuzu    5 cubic meter Fuel tank truck Isuzu    5 cubic meter Fuel tank truck Isuzu   5 cubic meter Fuel tank truck Isuzu
 Computer Fuel Dispenser    API Adaptor Valve    Bottom Valve    Manhole Cover
 ISUZU FUEL TANK TRUCKS ELF    ISUZU FUEL TANK TRUCKS ELF    FUEL TANK TRUCK ISUZU    ISUZU FUEL TANK TRUCKS ELF
 Ball Valve    Three Ways Set Ball Valve    Level Gauge    Oil and Gas Recovery Valve


Main specifications:

Model

PT5100GJY

Driving Type

4x2    (Left hand drive)

Wheelbase

4175 mm

Engine

139 kw (190hp)

Tyre

8.25-20

Tank

Material:

Carbon steel(Q345)

Shell Body

5 mm nominal thickness

Head

6 mm nominal thickness

Baffles

3mm nominal thick, wave shape, four pieces with Ø 500mm service port

Tank shape

Ellipse

Capacity

Full capacity 7000L

Compartment

No

Shell Finish

Shot blasted with 1anti-rust, 1 base coat and 1 finishing coat, the color of tank is according to customer requirement.

Testing Pressure

36kPa, Water pressure test

Tank Fittings

Top inlet port

2pieces

Manhole Cover

Aluminum alloy, 20” self-latching manhole cover, with air-van.

Outlet port:

One pneumatic sea valve which at the front of tank, the size of outlet port is 3 inches, fix all connector.

Pipe box:

It made of PVC material, round shape which on the both sides of tank, one plastic pipe (5m)

Anti –Static System:

Static electricity plate , copper plate and earth cable reel

Tank Accessories

Ladder:

Stainless Steel ladder fixed at rear of tank

Walkway Platform:

It fixed on the top of tank with anti – skid surface treatment.

Handrail:

No

Fire Extinguisher Housing:

2 units, suitable for 4 kg’s fire extinguisher

Pump Device

Yes

Flow meter

Yes

Tool box

Small box

Color

As option
