ABB AF50-30-00 1SBL357001R7000

1.AF50-30-00 1SBL357001R7000 we sell is 100% New Original Factory packing in good condition and have been tested before they are shipped. We will try our best to avoid any quality problems.

2.We will offer the technical support by experienced staff, which have undergone rigorous testing and certification!

3.We offer 12 month warranty after receiving parcels. If there are some workmanship or material defects with the products, please contact us firstly, we will exchange it or offer other solutions for you to make a choice.

4.If you order more than one item, please contact us, we can offer further discounts for you. And if you find other suppliers offer cheaper prices for the same product, we are also willing to provide you with reference to their price,even further discounts.

E-mail: plcinfo@mooreplc.com

AF50-30-00 1SBL357001R7000

Manufacturer(s)

ABB

General Information

Extended Product Type:
AF50-30-00 100-250V 50Hz / 100-250V 60Hz / 100-250V DC
Product ID:
1SBL357001R7000
EAN:
3471522114600
Catalog Description:
AF50-30-00 100-250V 50Hz / 100-250V 60Hz / 100-250V DC Contactor
Long Description:
AF50 contactors are mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits... The AF... contactors are fitted with an electronic coil interface which accepts a wide control voltage range, on AC 50/60 Hz or DC supplies. The same contactor can accept various supply voltages according to the different countries where the electrical equipment will be installed, or some fluctuation in the control voltage due to the local supply or network. The AF... contactors are also fully suitable for operation in AC or DC control circuit liable to voltage interruptions or voltage dip risks. Advantages: - Wide voltage range, e.g. 100 ... 250 V AC and DC - Can manage large voltage variations - Reduced power consumption - Very distinct closing and opening - Noise free - Can withstand voltage interruptions or voltage dips in the control supply (≤ 20 ms). The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks - Control circuit: AC or DC operated - Accessories: a wide range of accessories is available.

Categories
Products » Low Voltage Products and Systems » Control Products » Contactors » Block Contactors

 Minimum Order Quantity:
1 piece
Customs Tariff Number:
85364900
Popular Downloads
Data Sheet, Technical Information:
1SNC001003C0202
Instructions and Manuals:
FPTC407734P0003
Dimensions
Product Net Width:
70 mm
Product Net Depth / Length:
108 mm
Product Net Height:
110 mm
Product Net Weight:
1.180 kg
Technical
Number of Main Contacts NO:
3
Number of Main Contacts NC:
0
Number of Auxiliary Contacts NO:
0
Number of Auxiliary Contacts NC:
0
Rated Operational Voltage:
Main Circuit 690 V
Conventional Free-air Thermal Current (Ith):
acc. to IEC 60947-4-1, Open Contactors q = 40 °C 100 A
Rated Operational Current AC-1 (Ie):
(690 V) 40 °C 100 A
(690 V) 55 °C 85 A
(690 V) 70 °C 70 A
Rated Operational Current AC-3 (Ie):
(220 / 230 / 240 V) 55 °C 53 A
(380 / 400 V) 55 °C 50 A
(415 V) 55 °C 50 A
(440 V) 55 °C 45 A
(500 V) 55 °C 45 A
(690 V) 55 °C 35 A
Rated Operational Power AC-3 (Pe):
(220 / 230 / 240 V) 15 kW
(380 / 400 V) 22 kW
(415 V) 25 kW
(440 V) 25 kW
(500 V) 30 kW
(690 V) 30 kW
Short-Circuit Protective Devices:
gG Type Fuses 100 A
Maximum Breaking Capacity:
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 1300 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 630 A
Maximum Electrical Switching Frequency:
AC-1 300 cycles per hour
AC-2 / AC-4 150 cycles per hour
AC-3 300 cycles per hour
Rated Insulation Voltage (Ui):
acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V
acc. to UL/CSA 600 V
Rated Impulse Withstand Voltage (Uimp):
8 kV
Maximum Mechanical Switching Frequency:
300 cycles per hour
Rated Control Circuit Voltage (Uc):
50 Hz 100 ... 250 V
60 Hz 100 ... 250 V
DC Operation 100 ... 250 V
Coil Consumption:
Pull-in at Max. Rated Control Circuit Voltage 50 Hz 210 V·A
Pull-in at Max. Rated Control Circuit Voltage 60 Hz 210 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 7 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 2.8 W
Holding at Max. Rated Control Circuit Voltage 50 Hz 7 V·A
Holding at Max. Rated Control Circuit Voltage 50 Hz 2.8 W
Operate Time:
Between Coil Energization and NO Contact Closing 30 ... 100 ms
Between Coil De-energization and NO Contact Opening 30 ... 110 ms
Between Coil De-energization and NC Contact Closing 35 ... 115 ms
Connecting Capacity Main Circuit:
Flexible with Cable End 6 ... 16 mm²
Rigid Cable 6 ... 25 mm²
Connecting Capacity Auxiliary Circuit:
Flexible with Cable End 0.75 ... 2.5 mm²
Rigid Cable 1 ... 4 mm²
Degree of Protection:
acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20
Terminal Type:
Screw Terminals
Environmental
Ambient Air Temperature:
Close to Contactor Fitted with Thermal O/L Relay -25 ... +55 °C
Close to Contactor for Storage -60 ... +80 °C
Close to Contactor without Thermal O/L Relay -40 ... +70 °C
Maximum Operating Altitude Permissible:
3000 m
Resistance to Shock acc. to IEC 60068-2-27:
Shock Direction: A 20 g
Closed, Shock Direction: B1 10 g
Open, Shock Direction: B1 5 g
Shock Direction: B2 15 g
Shock Direction: C1 20 g
Shock Direction: C2 20 g
RoHS Status:
No declaration needed
Certificates and Declarations (Document Number)
CCC Certificate:
CCC_2008010304269002
CCC_2010010304402983
CSA Certificate:
CSA_1033838_LR056745
Declaration of Conformity - CE:
1SBD250803U1000
EAC Certificate:
EAC_RU C-FR ME77 B01010
Environmental Information:
1SBD250020E1002
GOST Certificate:
GOST_POCCFRME77B07175
Instructions and Manuals:
FPTC407734P0003
RMRS Certificate:
RMRS_1300130124
RoHS Information:
1SBC101059D0201
UL Certificate:
UL_20120830-E312527-10-1
UL Listing Card:
UL_E312527
Container Information
Package Level 1 Units:
1 piece
Package Level 1 Width:
140 mm
Package Level 1 Depth / Length:
146 mm
Package Level 1 Height:
96 mm
Package Level 1 Gross Weight:
1.18 kg
Package Level 1 EAN:
3471522114600
Package Level 2 Units:
20 piece
Package Level 2 Gross Weight:
23.6 kg
Classifications
Object Classification Code:
Q
E-nummer:
3228339
ETIM 4:
EC000066 - Magnet contactor, AC-switching
ETIM 5:
EC000066 - Magnet contactor, AC-switching
ETIM 6:
EC000066 - Power contactor, AC switching
UNSPSC:
39121529
